NSComm BE830-P5V2 WiFi 7 Dual-Band 3.6Gbps Ceiling Access Point with 2.5G PoE
NS BE830-P5V2 WiFi 7 BE3600 Ceiling Access Point
The NS BE830-P5V2 is a WiFi 7 (802.11be) dual-band ceiling access point designed for enterprise indoor deployments that require next-generation wireless efficiency, flexible networking, and cost-effective scalability.
Delivering up to 3.6 Gbps of dual-band wireless throughput, the BE830-P5V2 features a 2.5 Gbps Ethernet uplink, an additional Gigabit LAN port, and Qualcomm WiFi 7 chipset architecture. Supporting up to 128 concurrent clients, it is ideal for offices, classrooms, retail spaces, and hospitality environments transitioning from WiFi 6 to WiFi 7.
Overview
Highlights
-
Next-Generation WiFi 7 Performance
Built on the WiFi 7 (802.11be) standard, delivering improved spectral efficiency, lower latency, and better multi-user performance compared to WiFi 6. -
Balanced Dual-Band MIMO Design
Supports 2×2 MIMO on both 2.4 GHz and 5 GHz, providing stable, predictable wireless performance for enterprise indoor environments. -
2.5G Multi-Gigabit Uplink with LAN Port
Equipped with a 2.5 Gbps Ethernet uplink and an additional Gigabit Ethernet port, offering greater deployment flexibility for uplink or downstream connectivity. -
Flexible Indoor Deployment
Supports both ceiling-mounted and wall-mounted installation, adapting easily to different indoor layouts and renovation scenarios. -
Enterprise WLAN Capabilities
Supports VLAN, adjustable transmit power, high-density optimization, Fat/Thin AP modes, and seamless roaming. -
Centralized Cloud Management
Fully compatible with cloud management platforms for centralized configuration, monitoring, and lifecycle management.
Comparison with Similar Models
| Feature | NS BE830-P5V2 | NS BE830-P2V3 | H3C WA7xxx | Huawei AirEngine 6776-21 |
|---|---|---|---|---|
| Wi-Fi Standard | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) |
| Wireless Rate | BE3600 | BE3600 | BE3600 | BE3600 |
| MIMO | 2×2 (2.4G) + 2×2 (5G) | 2×2 + 2×2 | 2×2 + 2×2 | 2×2 + 2×2 |
| Ethernet Interface | 1×2.5G + 1×GE | 1×2.5G | 1×2.5G | 1×Multi-GE |
| Max Concurrent Clients | 128 | 128 | 128 | 128 |
| Power Supply | PoE (802.3at) / DC | PoE / DC | PoE | PoE |
| Mounting Options | Ceiling / Wall | Ceiling / Wall | Ceiling | Ceiling |
| Typical Positioning | Mainstream WiFi 7 AP | Cost-optimized WiFi 7 AP | Enterprise WiFi 7 AP | Enterprise WiFi 7 AP |
Positioning Summary:
-
BE830-P5V2: Mainstream WiFi 7 BE3600 AP with 2.5G uplink + LAN port, optimized for flexible enterprise deployments.
-
BE830-P2V3: Simplified WiFi 7 AP with single 2.5G uplink for large-scale, cost-controlled projects.
-
H3C / Huawei: Comparable enterprise WiFi 7 APs typically positioned for controller-centric WLAN architectures.
Specifications
| Parameter | Specification |
|---|---|
| Wi-Fi Standard | IEEE 802.11be (Wi-Fi 7) |
| Frequency Bands | 2.4 GHz + 5 GHz |
| Maximum Data Rate | BE3600 |
| MIMO | 2×2 (2.4 GHz), 2×2 (5 GHz) |
| Maximum Concurrent Clients | 128 |
| Ethernet Interfaces | 1× 2.5 Gbps Ethernet, 1× Gigabit Ethernet |
| Power Supply | 802.3at PoE / 12 V DC |
| Deployment Modes | Fat AP / Thin AP |
| Network Features | VLAN, adjustable TX power, high-density optimization |
| Management | Cloud management platform |
| Installation | Ceiling-mounted or wall-mounted |
| Dimensions | 198 × 198 × 37 mm |
| Application Scenarios | Offices, education, retail, hospitality |
