NSComm BE880-5262 WiFi 7 Tri-Band 10Gbps Ceiling Access Point with 10G SFP+ and PoE++
NS BE880-5262 WiFi 7 Tri-Band 10Gbps Ceiling Access Point
The NS BE880-5262 is a high-end WiFi 7 (802.11be) tri-band ceiling access point engineered for ultra-high-density enterprise environments that demand maximum wireless capacity, extreme concurrency, and flexible 10G backhaul options.
Delivering up to 10 Gbps of aggregate tri-band wireless throughput across 2.4 GHz, 5 GHz, and 6 GHz, the BE880-5262 features a 10G SFP+ optical uplink, a 10G Ethernet port, and an additional 2.5G Ethernet port with PoE output. Designed to support up to 384 concurrent clients, it is ideal for headquarters campuses, convention centers, large educational facilities, and mission-critical enterprise WLAN deployments.
Overview
Highlights
-
Flagship Tri-Band WiFi 7 Architecture
Simultaneous operation on 2.4 GHz, 5 GHz, and 6 GHz bands dramatically increases overall system capacity and minimizes congestion in ultra-dense environments. -
Ultra-High Wireless Throughput
Delivers up to 10 Gbps aggregate wireless performance, supporting bandwidth-intensive applications and next-generation enterprise services. -
Advanced MIMO Design for High Concurrency
Features 4×4 MIMO on 2.4 GHz and 2×2 MIMO on both 5 GHz and 6 GHz, optimizing performance for both legacy and next-generation clients. -
Flexible 10G Backhaul Options
Provides 1×10G SFP+ optical port and 1×10G Ethernet port, enabling seamless integration into modern enterprise core and aggregation networks. -
PoE Output for Network Expansion
Includes a 2.5G Ethernet port with 802.3at PoE output, allowing direct power and connectivity for downstream devices such as IP cameras or IoT equipment. -
Enterprise WLAN Features & Cloud Management
Supports VLAN, adjustable transmit power, seamless roaming, Fat/Thin AP modes, and centralized cloud management for large-scale deployments.
Comparison with Similar Models
| Feature | NS BE880-5262 | NS BE860-5262 | H3C WA8xxx | Huawei AirEngine 8771-X1T |
|---|---|---|---|---|
| Wi-Fi Standard | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) |
| Frequency Bands | 2.4G + 5G + 6G | 2.4G + 5G + 6G | 2.4G + 5G + 6G | 2.4G + 5G + 6G |
| Wireless Throughput | 10 Gbps | 9 Gbps | ~10 Gbps | ~10 Gbps |
| MIMO Configuration | 4×4 (2.4G) + 2×2 (5G) + 2×2 (6G) | 2×2 + 2×2 + 2×2 | 4×4 + 2×2 + 2×2 | 4×4 + 2×2 + 2×2 |
| Uplink Interfaces | 1×10G SFP+ + 1×10G RJ45 + 1×2.5G (PoE Out) | 1×10G SFP+ + 2×2.5G | 1×10G | 1×10G |
| Max Concurrent Clients | 384 | 192 | 384 | 384 |
| Power Supply | PoE (802.3bt) / DC 54V | PoE (802.3bt) / DC | PoE | PoE |
| Typical Positioning | Ultra-high-density flagship | High-density tri-band AP | Enterprise flagship AP | Enterprise flagship AP |
Positioning Summary:
-
BE880-5262: Ultra-high-density Wi-Fi 7 tri-band flagship AP with extreme concurrency and flexible 10G backhaul.
-
BE860-5262: High-density tri-band Wi-Fi 7 AP optimized for core enterprise deployments.
-
H3C / Huawei: Comparable flagship Wi-Fi 7 APs designed for large-scale, controller-centric WLAN architectures.
Specifications
| Parameter | Specification |
|---|---|
| Wi-Fi Standard | IEEE 802.11be (Wi-Fi 7) |
| Frequency Bands | 2.4 GHz + 5 GHz + 6 GHz |
| Maximum Data Rate | Up to 10 Gbps |
| MIMO | 4×4 (2.4 GHz), 2×2 (5 GHz), 2×2 (6 GHz) |
| Maximum Concurrent Clients | 384 |
| Ethernet Interfaces | 1×10G SFP+, 1×10G Ethernet (RJ45), 1×2.5G Ethernet (PoE Out) |
| Power Supply | 802.3bt PoE / 54 V DC |
| Deployment Modes | Fat AP / Thin AP |
| Network Features | VLAN, adjustable TX power, seamless roaming |
| Management | Cloud management platform |
| Installation | Ceiling-mounted or wall-mounted |
| Application Scenarios | Campuses, convention centers, large enterprises, ultra-high-density WLANs |
