NSComm FAP855 WiFi 7 Dual-Band 3.6Gbps In-Wall Access Point with 2.5G PoE
NS FAP855 WiFi 7 BE3600 Multi-Port In-Wall Access Point
The NS FAP855 is a commercial-grade WiFi 7 (802.11be) in-wall access point designed for next-generation enterprise and hospitality networks that demand higher capacity, lower latency, and multi-gigabit uplink performance.
Delivering up to 3.6 Gbps dual-band wireless throughput, the FAP855 integrates a 2.5 Gbps Ethernet uplink, four Gigabit LAN ports, and dual pass-through interfaces into a large 86×160 mm in-wall form factor. Supporting up to 128 concurrent devices, it is ideal for hotels, hospitals, office rooms, and smart building deployments.
Overview
Highlights
-
Next-Generation WiFi 7 Performance
Built on the WiFi 7 (802.11be) standard, delivering higher spectral efficiency, reduced latency, and improved performance in high-density environments. -
Multi-Gigabit Wired Backhaul
Equipped with a 2.5 Gbps Ethernet uplink, ensuring sufficient wired bandwidth for WiFi 7 traffic and future network upgrades. -
Integrated Multi-Port Room Connectivity
Provides 4× Gigabit Ethernet LAN ports, enabling direct connection of IP phones, TVs, desktops, printers, and other wired devices. -
Dual Pass-Through Interfaces
Includes 1 pair of pass-through ports, allowing existing cables or services to pass through the wall box without additional wiring. -
Large 86×160 mm In-Wall Design
Designed for 86×160 mm wall-mounted boxes, ideal for hospitality and enterprise rooms with centralized weak-current wiring. -
Enterprise WLAN Features & Cloud Management
Supports VLAN, adjustable transmit power, seamless roaming, Fat/Thin AP modes, and centralized cloud management.
Comparison with Similar Models
| Feature | NS FAP855 | NS FAP655 | H3C EWP-WA7xxx | Huawei AirEngine 5763-12W |
|---|---|---|---|---|
| Wi-Fi Standard | WiFi 7 (802.11be) | WiFi 6 (802.11ax) | WiFi 7 (802.11be) | WiFi 7 (802.11be) |
| Wireless Rate | BE3600 | AX3000 | BE3600 | BE3600 |
| Uplink Interface | 2.5 Gbps Ethernet | 1 Gbps Ethernet | 2.5 Gbps | 2.5 Gbps |
| LAN Ports | 4× Gigabit Ethernet | 4× Gigabit Ethernet | 4× GE | 4× GE |
| Pass-Through Ports | Yes (1 pair) | Yes | Optional | Optional |
| Panel Size | 86×160 mm | 86×160 mm | Large in-wall | Large in-wall |
| Max Concurrent Devices | 128 | 128 | 128 | 128 |
| Typical Positioning | Wi-Fi 7 room AP | Wi-Fi 6 room AP | Enterprise Wi-Fi 7 AP | Enterprise Wi-Fi 7 AP |
Positioning Summary:
-
FAP855: Wi-Fi 7 commercial in-wall AP with Multi-Gig uplink and multi-port room connectivity.
-
FAP655: Wi-Fi 6 in-wall AP for mature Ethernet environments.
-
H3C / Huawei: Comparable enterprise-grade Wi-Fi 7 room APs for next-generation WLAN deployments.
Specifications
| Parameter | Specification |
|---|---|
| Wi-Fi Standard | IEEE 802.11be (WiFi 7) |
| Frequency Bands | 2.4 GHz + 5 GHz |
| Maximum Data Rate | BE3600 |
| MIMO | 2×2 (2.4 GHz), 2×2 (5 GHz) |
| Antenna Design | 4× internal omnidirectional antennas |
| Maximum Concurrent Devices | 128 |
| Ethernet Interfaces | 1×2.5 Gbps uplink, 4×Gigabit LAN |
| Pass-Through Ports | 1 pair |
| Power Supply | Standard PoE |
| Deployment Modes | Fat AP / Thin AP |
| Network Features | VLAN, adjustable TX power, seamless roaming |
| Management | Cloud management platform |
| Installation | In-wall (86×160 mm wall box) |
| Application Scenarios | Hotels, hospitals, offices, smart rooms, enterprise buildings |
