NSComm BE830-P2v3 WiFi 7 Dual-Band 3.6Gbps Ceiling Access Point with 2.5G PoE
NS BE830-P2V3 WiFi 7 BE3600 Ceiling Access Point
The NS BE830-P2V3 is a WiFi 7 (802.11be) dual-band ceiling access point designed for enterprise indoor deployments that require next-generation wireless efficiency with a simplified, cost-effective hardware design.
Delivering up to 3.6 Gbps of dual-band wireless throughput, the BE830-P2V3 features a single 2.5 Gbps Ethernet uplink, Qualcomm WiFi 7 chipset architecture, and support for up to 128 concurrent clients. It is ideal for offices, classrooms, retail spaces, and hospitality environments upgrading from WiFi 6 to WiFi 7.
Overview
Highlights
-
Next-Generation WiFi 7 Efficiency
Built on the WiFi 7 (802.11be) standard, delivering improved spectral efficiency, lower latency, and better multi-user performance compared to WiFi 6. -
Balanced Dual-Band Architecture
Supports 2×2 MIMO on both 2.4 GHz and 5 GHz, providing stable, predictable performance for enterprise indoor environments. -
2.5G Single-Port Uplink Design
Equipped with a 2.5 Gbps Ethernet uplink, eliminating Gigabit bottlenecks while maintaining a streamlined hardware configuration. -
Flexible Indoor Deployment
Supports both ceiling-mounted and wall-mounted installation, enabling easy deployment across diverse indoor layouts. -
Enterprise WLAN Features
Supports VLAN, adjustable transmit power, high-density optimization, Fat/Thin AP modes, and seamless integration into enterprise WLAN architectures. -
Centralized Cloud Management
Fully compatible with cloud management platforms for centralized configuration, monitoring, and lifecycle management.
Comparison with Similar Models
| Feature | NS BE830-P2V3 | NS BE730 | H3C WA7xxx | Huawei AirEngine 6776-21 |
|---|---|---|---|---|
| Wi-Fi Standard | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) |
| Wireless Rate | BE3600 | BE3600 | BE3600 | BE3600 |
| MIMO | 2×2 (2.4G) + 2×2 (5G) | 2×2 + 3×3 (5G radio) | 2×2 + 2×2 | 2×2 + 2×2 |
| Ethernet Interface | 1×2.5G | 1×2.5G + 1×GE | 1×2.5G | 1×Multi-GE |
| Max Concurrent Clients | 128 | 128 | 128 | 128 |
| Power Supply | PoE (802.3at) / DC | PoE / DC | PoE | PoE |
| Mounting Options | Ceiling / Wall | Ceiling / Wall | Ceiling | Ceiling |
| Typical Positioning | Cost-effective WiFi 7 AP | Entry WiFi 7 AP with dual ports | Enterprise WiFi 7 AP | Enterprise WiFi 7 AP |
Positioning Summary:
-
BE830-P2V3: Simplified WiFi 7 BE3600 AP with single 2.5G uplink, optimized for cost-effective enterprise upgrades.
-
BE730: Entry WiFi 7 AP with additional LAN port and enhanced antenna configuration.
-
H3C / Huawei: Comparable enterprise WiFi 7 APs typically deployed in controller-centric WLAN architectures.
Specifications
| Parameter | Specification |
|---|---|
| Wi-Fi Standard | IEEE 802.11be (Wi-Fi 7) |
| Frequency Bands | 2.4 GHz + 5 GHz |
| Maximum Data Rate | BE3600 |
| MIMO | 2×2 (2.4 GHz), 2×2 (5 GHz) |
| Maximum Concurrent Clients | 128 |
| Ethernet Interfaces | 1× 2.5 Gbps Ethernet (RJ45) |
| Power Supply | 802.3at PoE / 12 V DC |
| Deployment Modes | Fat AP / Thin AP |
| Network Features | VLAN, adjustable TX power, high-density optimization |
| Management | Cloud management platform |
| Installation | Ceiling-mounted or wall-mounted |
| Application Scenarios | Offices, education, retail, hospitality |
