NSComm BE-HQ830 WiFi 7 Dual-Band 3.6Gbps Outdoor Access Point with 2.5G PoE
NS BE-HQ830 WiFi 7 BE3600 Outdoor Access Point
The NS BE-HQ830 is a WiFi 7 (802.11be) dual-band outdoor access point designed for enterprise and industrial outdoor deployments that require next-generation wireless efficiency, long-range coverage, and rugged environmental protection.
Delivering up to 3.6 Gbps of dual-band wireless throughput, the BE-HQ830 features a 2.5 Gbps Ethernet uplink, integrated 360° omnidirectional antennas, and a weather-resistant IP67 enclosure. With a coverage radius of up to 100 meters and support for 128 concurrent clients, it is ideal for campuses, industrial parks, logistics areas, outdoor corridors, and smart city deployments.
Overview
Highlights
-
Next-Generation Outdoor WiFi 7 Performance
Built on the WiFi 7 (802.11be) standard, delivering higher efficiency, lower latency, and improved multi-user performance compared to WiFi 6 outdoor APs. -
Wide-Area Omnidirectional Coverage
Equipped with 2 built-in 360° omnidirectional antennas, providing consistent signal coverage with a typical outdoor radius of up to 100 meters. -
2.5G Multi-Gigabit Backhaul
Features a 2.5 Gbps Ethernet port plus an additional Gigabit LAN port, ensuring sufficient wired backhaul for high-throughput outdoor wireless traffic. -
Rugged IP67 Outdoor Design
UV-resistant plastic housing with IP67 protection ensures stable operation under rain, dust, heat, and harsh outdoor conditions. -
Industrial-Grade Protection
Independent lightning and surge protection safeguards equipment and network stability in outdoor and elevated installations. -
Enterprise WLAN Features & Cloud Management
Supports VLAN, adjustable transmit power, seamless roaming, Fat/Thin AP modes, and centralized cloud management for scalable outdoor networks.
Comparison with Similar Models
| Feature | NS BE-HQ830 | NS AX-HQ830-P5 | H3C WA7xxx-Outdoor | Huawei AirEngine 6776-Outdoor |
|---|---|---|---|---|
| Wi-Fi Standard | Wi-Fi 7 (802.11be) | Wi-Fi 6 (802.11ax) | Wi-Fi 7 (802.11be) | Wi-Fi 7 (802.11be) |
| Wireless Rate | BE3600 | AX3000 | BE3600 | BE3600 |
| Frequency Bands | 2.4G + 5G | 2.4G + 5G | 2.4G + 5G | 2.4G + 5G |
| MIMO | 2×2 + 2×2 | 2×2 + 2×2 | 2×2 + 2×2 | 2×2 + 2×2 |
| Uplink Interface | 1×2.5G + 1×GE | 1×2.5G + 1×GE | 1×2.5G | 1×Multi-GE |
| Coverage Radius | Up to 100 m | Up to 60 m | ~80-100 m | ~80-100 m |
| Outdoor Protection | IP67 | IP67 | IP67 | IP67 |
| Max Concurrent Clients | 128 | 128 | 128 | 128 |
| Typical Positioning | Wi-Fi 7 outdoor mainstream AP | Wi-Fi 6 outdoor AP | Enterprise Wi-Fi 7 outdoor AP | Enterprise Wi-Fi 7 outdoor AP |
Positioning Summary:
-
BE-HQ830: Mainstream Wi-Fi 7 outdoor AP with extended coverage and 2.5G backhaul.
-
AX-HQ830-P5: Proven Wi-Fi 6 outdoor AP for existing deployments.
-
H3C / Huawei: Comparable enterprise Wi-Fi 7 outdoor APs designed for large-scale controller-based WLANs.
Specifications
| Parameter | Specification |
|---|---|
| Wi-Fi Standard | IEEE 802.11be (Wi-Fi 7) |
| Frequency Bands | 2.4 GHz + 5 GHz |
| Maximum Data Rate | BE3600 |
| MIMO | 2×2 (2.4 GHz), 2×2 (5 GHz) |
| Antenna Design | 2 built-in omnidirectional antennas, 360° coverage |
| Coverage Radius | Up to 100 m (typical outdoor environment) |
| Maximum Concurrent Clients | 128 |
| Ethernet Interfaces | 1×2.5 Gbps Ethernet, 1×Gigabit Ethernet |
| Power Supply | 48 V PoE (802.3at) |
| Deployment Modes | Fat AP / Thin AP |
| Network Features | VLAN, adjustable TX power, seamless roaming |
| Management | Cloud management platform |
| Protection Rating | IP67, UV-resistant enclosure |
| Installation | Pole-mounted or wall-mounted |
| Application Scenarios | Campuses, industrial parks, logistics zones, outdoor corridors |
