NSComm APH6-AX3000D WiFi 6 AX3000 Dual-Band Outdoor Directional Access Point with SFP
NS APH6-AX3000D WiFi 6 AX3000 Directional Outdoor Access Point
The NS APH6-AX3000D is a commercial-grade WiFi 6 (802.11ax) directional outdoor access point designed for long-distance, point-focused wireless coverage in enterprise and industrial environments.
Delivering AX3000 dual-band wireless performance, the APH6-AX3000D features built-in high-gain directional antennas, fiber and Ethernet uplink options, and a full die-cast aluminum IP67 enclosure. With a coverage distance of over 400 meters, it is ideal for roads, factory corridors, campus perimeters, ports, mining areas, and other linear outdoor scenarios.
Overview
Highlights
-
High-Efficiency WiFi 6 Outdoor Performance
Built on the WiFi 6 (802.11ax) standard, providing improved spectral efficiency, stable multi-user access, and lower latency in outdoor deployments. -
Directional Antenna Design for Long-Distance Coverage
Integrated directional antennas with >120° beamwidth, enabling focused signal transmission and reception with coverage distances exceeding 400 meters. -
Flexible Fiber + Ethernet Backhaul
Supports 1× Gigabit SFP fiber port and 2× Gigabit Ethernet ports, allowing flexible integration into fiber-based or traditional Ethernet outdoor networks. -
Industrial-Grade IP67 Protection
Full die-cast aluminum housing with IP67 rating ensures resistance to rain, dust, UV exposure, and harsh environmental conditions. -
Lightning & Surge Protection
Built-in port-level lightning and surge protection enhances network reliability in exposed outdoor installations. -
Enterprise WLAN Features & Cloud Management
Supports VLAN, adjustable transmit power, seamless roaming, unified Fat/Thin AP modes, and centralized cloud management.
Comparison with Similar Models
| Feature | NS APH6-AX3000D | NS APH6-AX3000 | H3C WA6320-Outdoor-D | Huawei AirEngine 5762-Outdoor-D |
|---|---|---|---|---|
| Wi-Fi Standard | WiFi 6 (802.11ax) | WiFi 6 (802.11ax) | WiFi 6 (802.11ax) | WiFi 6 (802.11ax) |
| Wireless Rate | AX3000 | AX3000 | AX3000 | AX3000 |
| Antenna Type | Built-in directional | External omnidirectional | Directional | Directional |
| Coverage Distance | >400 m | Up to 150 m | ~300-400 m | ~300-400 m |
| Beamwidth | >120° | 360° | Directional | Directional |
| Uplink Interfaces | 1×SFP + 2×GE | 1×SFP + 2×GE | GE | GE |
| Enclosure | Die-cast aluminum | Die-cast aluminum | Industrial housing | Industrial housing |
| Protection Rating | IP67 | IP67 | IP67 | IP67 |
| Max Concurrent Clients | 128 | 128 | 128 | 128 |
| Typical Positioning | Long-range directional AP | Wide-area outdoor AP | Enterprise directional AP | Enterprise directional AP |
Positioning Summary:
-
APH6-AX3000D: WiFi 6 outdoor AP optimized for long-distance directional coverage.
-
APH6-AX3000: WiFi 6 outdoor AP designed for wide-area omnidirectional coverage.
-
H3C / Huawei: Comparable enterprise-grade directional outdoor APs for standardized outdoor deployments.
Specifications
| Parameter | Specification |
|---|---|
| Wi-Fi Standard | IEEE 802.11ax (WiFi 6) |
| Frequency Bands | 2.4 GHz + 5 GHz |
| Maximum Data Rate | AX3000 |
| MIMO | 2×2 (2.4 GHz), 2×2 (5 GHz) |
| Antenna Design | Built-in directional antennas (>120° beamwidth) |
| Coverage Distance | >400 m (typical outdoor environment) |
| Maximum Concurrent Devices | 128 |
| Ethernet Interfaces | 2× Gigabit Ethernet |
| Fiber Interface | 1× Gigabit SFP |
| Power Supply | 48 V PoE (802.3at) / 12 V DC |
| Deployment Modes | Fat AP / Thin AP |
| Network Features | VLAN, adjustable TX power, seamless roaming |
| Management | Cloud management platform |
| Protection Rating | IP67, full die-cast aluminum housing |
| Installation | Pole-mounted |
| Optional Features | Bluetooth / GPS |
| Application Scenarios | Roads, factory corridors, campuses, ports, mining areas |
