NSComm S6510-4C Modular 25G/100G Data Center Switch

Product image 1
Product image 2

NSComm S6510-4C Modular 25G/100G Data Center Switch

NSComm S6510-4C Modular 25G/100G Data Center Switch

Modular 4-Slot 2 RU Layer 3 Data Center Switch

As a manufacturer alongside leading brands like Cisco, H3C, Huawei, and Ruijie, NSComm delivers high-performance data-center and spine/leaf aggregation switches under the NS-S6500/6580/6520/6510 series.

These devices match Ruijie’s RG-S6580, RG-S6520, and RG-S6510 Series in port density, non-blocking throughput, virtualization (VSU), advanced fabric features (EVPN-VXLAN, M-LAG), hardware redundancy, and lossless Ethernet support, all under your own NS-branding.

Overview

OEM equivalent of Ruijie’s RG-S6510-4C. A 2 RU chassis supporting four line-card slots (M6500-24VS2CQ & M6500-08CQ). Scale to up to 96 × 25 GbE or 32 × 100 GbE ports with unified VSU, VXLAN, and advanced L3 features.

Highlights

  • Modular Flexibility: Up to 96×25 GbE or 32×100 GbE via hot-plug cards

  • 6.4 Tbps switching / 4 800 Mpps forwarding

  • VSU virtualization, VXLAN, EVPN, M-LAG

  • Carrier-class reliability: 1+1 PSUs; 2+1 fans

  • Rich L2/L3 & security: ACL, QoS, OSPF, BGP, RIP, VRRP

Recommended Accessories

Product Name Category Description
NS-PA800I-F AC Power Module 800 W hot-swap PSU
NS-PA800I-R Redundant PSU Redundant PSU variant
NS-RMK-2U Rack Mount Kit 19″ 2 RU mounting brackets


Compare with Similar Models

Model Ports & Uplinks Switching Capacity Forwarding Rate Redundancy Features
Ruijie RG-S6580-48CQ8QC 48×100 GbE DSFP + 8×400 GbE QSFP-DD 16.0 Tbps 5 350 Mpps 1+1 PSUs; 5+1 fans
NS-S6580-48CQ8QC Same Same Same Same
Ruijie RG-S6580-24DC8QC 24×200 GbE QSFP56 + 8×400 GbE QSFP-DD 16.0 Tbps 5 350 Mpps 1+1 PSUs; 5+1 fans
NS-S6580-24DC8QC Same Same Same Same
Ruijie RG-S6520-64CQ 64×100 GbE QSFP28 12.8 Tbps 4 482 Mpps 1+1 PSUs; 2+1 fans
NS-S6520-64CQ Same Same Same Same
Ruijie RG-S6510-4C Modular 4 slots (max 96×25 GbE or 32×100 GbE) 6.4 Tbps 4 800 Mpps 1+1 PSUs; 2+1 fans
NS-S6510-4C Same Same Same Same
Ruijie RG-S6510-48VS8CQ 48×25 GbE SFP28 + 8×100 GbE QSFP28 4.0 Tbps 2 000 Mpps 1+1 PSUs; 2+1 fans
NS-S6510-48VS8CQ Same Same Same Same
Ruijie RG-S6510-32CQ 32×100 GbE QSFP28 6.4 Tbps 2 030 Mpps 1+1 PSUs; 2+1 fans
NS-S6510-32CQ Same Same Same Same


Specification Summary

Parameter Specification Details
Model NS-S6510-4C
Slot Configuration 4× M6500-24VS2CQ (24×25 GbE + 2×100 GbE) or M6500-08CQ (8×100 GbE)
Maximum Ports 96×25 GbE or 32×100 GbE
Switching Capacity 6.4 Tbps
Forwarding Rate 4 800 Mpps
MAC Address Table 256 K entries
ARP Table Size 8 K entries
IPv4/IPv6 Routes 64 K / 32 K entries
Redundancy 1+1 PSUs; 2+1 fans
Dimensions (W×D×H) 442×480×44 mm
Operating Temperature

0 °C – 40 °C


More Details

Quality Certifications

product_iso14001   product_iso9001   product_rohs   product_reach    product_ce      product_fcc

Do you have any question about the NSComm S6510-4C Modular Switch?

Please Chat with us now!

or leave us an message on [email protected]

Warranty

100% Low Price Guarantee

Network-switch.com provides high-quality products at low wholesale prices

100% Quality Assurance

All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Certified Engineers.

Free Technical Support

Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.

100% Money Back Guarantee

You can contact our customer service team to exchange or return any product that you bought from us.

Flexible Secure Payment & Shipment

Verified authorization: Mcafee Secure, VeriSign Secured

Return Material Authorization (RMA) Process

Standard Warranty Policy

Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year

The Support Contacts

If your NSComm products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
