NSComm S2300-8GT4SFP 8 x 1G & 4 x 1G SFP Access Switch
NS‑S2300‑8GT4SFP – 8‑Port Gigabit Managed Switch with 4×1 Gbps SFP Uplinks
As one of the trusted manufacturers alongside Cisco, H3C, Huawei, and Ruijie, NSComm offers equivalent high-quality products with the same performance and specifications as leading brands. Our NS‑S2300 series provide identical performance under your own brand label.
Overview
Compact but full-featured, the NS‑S2300‑8GT4SFP delivers the same performance as RG‑S2300‑8GT4SFP. With 8 Gigabit downlinks and 4 fiber uplinks, it's ideal for small offices or branch deployments needing efficient Layer 2 switching.
Highlights
-
Perfect for SMBs: Small form factor with full gigabit and fiber uplink options.
-
Reliable Throughput: Same 56 Gbps switching capacity and ~41.6 Mpps forwarding rate.
-
Fanless & Quiet: Office‑friendly design with low heat and noise.
-
Layer 2 Feature-Rich: VLAN, QoS, link aggregation, security enforcement via IP/MAC binding, ARP protection.
-
Convenient Management: SNMP, Web GUI, CLI options available.
Recommended Accessories
| Accessory | Description |
|---|---|
| NS‑PA600I‑P‑F (Power Module) | 240 W AC power supply module (same footprint as Ruijie RG‑PA600I) |
| Mini‑GBIC‑GT / SX / LX SFP | Compatible 1 Gbps SFP transceivers (copper/fiber options: 850 nm, 1310 nm) |
| XG‑SFP‑SR / LR SFP+ | Compatible 10G SFP+ modules for short‑range & long‑range fiber links |
| 1U Rack Mount Kit | For secure rack installation into standard 19″ enclosures |
Compare with Similar Models
| Model | Downlink Ports | Uplink Ports | Switching Capacity | Forward Rate | Brand |
|---|---|---|---|---|---|
| Ruijie RG‑S2300‑24GT4XS | 24×Gigabit Ethernet | 4×1/10 Gbps SFP+ | 128 Gbps | 96 Mpps | Ruijie |
| NS‑S2300‑24GT4XS | 24×Gigabit Ethernet | 4×1/10 Gbps SFP+ | 128 Gbps | 96 Mpps | Network‑Switch (our brand) |
| Ruijie RG‑S2300‑24GT4SFP | 24×Gigabit Ethernet | 4×1 Gbps SFP | 56 Gbps | 41.66 Mpps | Ruijie |
| NS‑S2300‑24GT4SFP | 24×Gigabit Ethernet | 4×1 Gbps SFP | 56 Gbps | 41.66 Mpps | Network‑Switch |
| Ruijie RG‑S2300‑8GT4SFP | 8×Gigabit Ethernet | 4×1 Gbps SFP | 56 Gbps | ~41.6 Mpps | Ruijie |
| NS‑S2300‑8GT4SFP | 8×Gigabit Ethernet | 4×1 Gbps SFP | 56 Gbps | ~41.6 Mpps | Network‑Switch |
Specification Summary
| Parameter | Specification |
|---|---|
| Model | NS‑S2300‑8GT4SFP |
| Ports | 8×10/100/1000BASE‑T; 4×1 Gbps SFP |
| PoE Support | None |
| Switching Capacity | 56 Gbps |
| Forwarding Rate | ~41.66 Mpps |
| MAC Table Entries | ~16,000 |
| VLANs Supported | Up to 4,094 |
| Operating Temp | 0 °C to 50 °C |
| Dimensions & Weight | Compact desktop or rack-friendly (~2 kg)* |
| Ingress Protection | IP40 |
| Management | SNMP / Web / CLI |
| MTBF | ~200,000 hours |
