NSComm S6510-48VS8CQ 48x25G & 8x100G Data Center Switch

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6

NSComm S6510-48VS8CQ 48x25G & 8x100G Data Center Switch

NSComm S6510-48VS8CQ 48x25G & 8x100G Data Center Switch

48 × 25 Gbps SFP28 + 8 × 100 Gbps QSFP28 Layer 3 Data Center Switch

As a manufacturer alongside leading brands like Cisco, H3C, Huawei, and Ruijie, NSComm delivers high-performance data-center and spine/leaf aggregation switches under the NS-S6500/6580/6520/6510 series.

These devices match Ruijie’s RG-S6580, RG-S6520, and RG-S6510 Series in port density, non-blocking throughput, virtualization (VSU), advanced fabric features (EVPN-VXLAN, M-LAG), hardware redundancy, and lossless Ethernet support, all under your own NS-branding.

Overview

OEM version of Ruijie’s RG-S6510-48VS8CQ. Integrates 48 SFP28 25 Gbps downlinks and 8 QSFP28 100 Gbps uplinks in 1 RU, with line-rate L2/L3, VSU, and lossless Ethernet features.

Highlights

  • 4.0 Tbps switching / 2 000 Mpps forwarding

  • 48×25 GbE SFP28 + 8×100 GbE QSFP28

  • VSU, VXLAN, M-LAG for sub-200 ms failover

  • PFC & ECN for zero-loss RDMA

  • 1+1 PSUs; 2+1 fans

Recommended Accessories

Product Name Category Description
NS-PA550I-F AC Power Module 550 W hot-swap PSU
NS-RMK-1U Rack Mount Kit 19″ 1 RU mounting brackets


Compare with Similar Models

Model Ports & Uplinks Switching Capacity Forwarding Rate Redundancy Features
Ruijie RG-S6580-48CQ8QC 48×100 GbE DSFP + 8×400 GbE QSFP-DD 16.0 Tbps 5 350 Mpps 1+1 PSUs; 5+1 fans
NS-S6580-48CQ8QC Same Same Same Same
Ruijie RG-S6580-24DC8QC 24×200 GbE QSFP56 + 8×400 GbE QSFP-DD 16.0 Tbps 5 350 Mpps 1+1 PSUs; 5+1 fans
NS-S6580-24DC8QC Same Same Same Same
Ruijie RG-S6520-64CQ 64×100 GbE QSFP28 12.8 Tbps 4 482 Mpps 1+1 PSUs; 2+1 fans
NS-S6520-64CQ Same Same Same Same
Ruijie RG-S6510-4C Modular 4 slots (max 96×25 GbE or 32×100 GbE) 6.4 Tbps 4 800 Mpps 1+1 PSUs; 2+1 fans
NS-S6510-4C Same Same Same Same
Ruijie RG-S6510-48VS8CQ 48×25 GbE SFP28 + 8×100 GbE QSFP28 4.0 Tbps 2 000 Mpps 1+1 PSUs; 2+1 fans
NS-S6510-48VS8CQ Same Same Same Same
Ruijie RG-S6510-32CQ 32×100 GbE QSFP28 6.4 Tbps 2 030 Mpps 1+1 PSUs; 2+1 fans
NS-S6510-32CQ Same Same Same Same


Specification Summary

Parameter Specification Details
Model NS-S6510-48VS8CQ
Downlink / Uplink Ports 48×25 GbE SFP28, 8×100 GbE QSFP28
Switching Capacity 4.0 Tbps
Forwarding Rate 2 000 Mpps
Redundancy 1+1 PSUs; 2+1 fans
Dimensions (W×D×H) 442×340×44 mm
Operating Temperature 0 °C – 45 °C
