NSComm S6250-48XS8CQ 48x10G SFP+ & 8x100G QSFP28 Data Center Access Switch
48×1/10 Gbps SFP+ + 8×100 Gbps QSFP28 Data Center Access Switch
Overview
The NS-S6250-48XS8CQ brings high-density fiber access to leaf-spine and campus-core layers with 48 × 1/10 Gbps SFP+ ports, 8 × 100 Gbps QSFP28 uplinks, and a non-blocking 2.56 Tbps switching fabric at 1 920 Mpps.
It features VSU, M-LAG, VXLAN, and PFC/ECN for lossless Ethernet, plus 1+1 PSU and 3+1 fan redundancy.
Highlights
-
2.56 Tbps / 1 920 Mpps non-blocking architecture
-
48×SFP+ & 8×QSFP28 for flexible 10 GbE and 100 GbE connectivity
-
Carrier-Class Redundancy: Dual hot-swap PSUs, 3+1 fan modules
-
Advanced Fabric Virtualization: VSU2.0, M-LAG, VXLAN, EVPN
-
Lossless Ethernet: PFC & ECN with RDMA support
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS-PA550I-F | AC Power Module | 550 W hot-swap PSU (AC & HVDC) |
| NS-PA550I-R | Redundant PSU Module | Redundant PSU variant |
| NS-M1EFAN-II-F | Fan Module | Hot-swappable fan module (3+1 redundancy) |
| NS-RMK-1U | Rack Mount Kit | 19″ 1 RU mounting brackets |
Compare with Similar Models
| Model | Ports & Uplinks | Switching Capacity | Forwarding Rate | PoE/PoF Capability | Redundancy Features |
|---|---|---|---|---|---|
| Ruijie RG-S6232-48XS8CQ | 48×10 Gbps SFP+ & 8×100 Gbps QSFP28 | 4.8 Tbps | 2 000 Mpps | None | Dual hot-swap PSUs, 3+1 hot-swap fan modules |
| NS-S6232-48XS8CQ | Same | Same | Same | Same | Same |
| Ruijie RG-S6231-48XT8CQ | 48×10 Gbps BASE-T & 8×100 Gbps QSFP28 | 4.8 Tbps | 2 000 Mpps | None | 2 PSU slots (1+1), 4 fan slots (3+1) |
| NS-S6231-48XT8CQ | Same | Same | Same | Same | Same |
| Ruijie RG-S6250-48XS8CQ | 48×10 Gbps SFP+ & 8×100 Gbps QSFP28 | 2.56 Tbps | 1 920 Mpps | None | Dual hot-swap PSUs, 3+1 hot-swap fan modules |
| NS-S6250-48XS8CQ | Same | Same | Same | Same | Same |
Specification Summary
| Parameter | Specification Details |
|---|---|
| Model | NS-S6250-48XS8CQ |
| Downlink Ports | 48×1/10 Gbps SFP+ |
| Uplink Ports | 8×100 Gbps QSFP28 (auto-40/100 Gbps) |
| Switching Capacity | 2.56 Tbps |
| Forwarding Rate | 1 920 Mpps |
| MAC Address Table | 320 K entries |
| IPv4/IPv6 Route Entries | 64 K / 32 K |
| Virtualization | VSU2.0, M-LAG, VXLAN, EVPN |
| Redundancy | Dual PSU slots (1+1), 3+1 fan modules |
| Dimensions (W×D×H) | 442 × 387 × 44 mm |
| Weight | ~8.5 kg (with PSUs & fans) |
| Management | SNMPv3, SSH, Telnet, Web UI, USB, RMON |
| Power Input | AC 100–240 V; HVDC 240 V DC |
| Operating Temperature | 0 °C – 45 °C, non-condensing |
