NSComm S5360-24GT4XS-P-E 24x1G (PoE+) & 4x10G SFP+ L3 PoE Switch
NS‑S5360‑24GT4XS‑P‑E, 24 × 1 Gbps PoE+ RJ45 + 4 × 10 Gbps SFP+ Layer 3 PoE Switch
As a trusted OEM partner alongside Cisco, H3C, Huawei, and Ruijie, NSComm offers exactly the same hardware, firmware (RGOS 12.X), and industrial‑grade reliability of Ruijie’s RG‑S5360‑24GT4XS‑E under your brand label.
Our NS‑S5360‑E series delivers enterprise‑grade Layer 3 routing, virtualization (VSU), robust security, and flexibility of uplinks and PoE configurations across 24‑port and 48‑port models.
Overview
Supports IEEE 802.3af/at PoE+ on 24 downlinks, full redundancy power modules, 154 Gbps switching, 115 Mpps forwarding. Ideal for powering APs, IP cameras, VoIP devices.
Highlights
-
Up to 740 W total PoE budget, with 30 W per port
-
Same robust Layer 2+/Layer 3 protocol support as non‑PoE models
-
Industrial-grade durability and power redundancy
-
VSU for centralized management
-
Supports SNMP, Web, CLI, Telnet, TR‑069 zero‑touch
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS‑PA600I‑P‑F | AC Power Module | 600 W module, supports up to 740 W PoE |
| NS‑PA1000I‑P‑F | AC Power Module | 1000 W PSU for larger PoE demands |
| NS‑PA70IB | AC Power Module | 70 W base module for minimal load |
| NS‑XG‑SFP‑SR | SFP+ Transceiver | 10 G SR multimode fiber module |
| NS‑RMK‑1U | Rack Mount Kit | 19″ 1 U mounting kit |
Compare with Similar Models
| Model | Ports & Uplinks | Capacity / Forwarding | PoE+ Budget | Power Redundancy |
|---|---|---|---|---|
| Ruijie RG‑S5360‑24GT4XS‑E | 24 × GE + 4 × 10 GE SFP+ | 154 Gbps / 115 Mpps | None | Dual hot-swap PSUs |
| NS‑S5360‑24GT4XS‑E | Same | Same | None | Same |
| Ruijie RG‑S5360‑48GT4XS‑E | 48 × GE + 4 × 10 GE SFP+ | 211 Gbps / 158 Mpps | None | Dual PSUs |
| NS‑S5360‑48GT4XS‑E | Same | Same | None | Same |
| Ruijie RG‑S5360‑24GT4XS‑P‑E | 24 × GE PoE+ + 4 × 10 GE SFP+ | 154 Gbps / 115 Mpps | Up to 740 W | PoE PSU Redundancy |
| NS‑S5360‑24GT4XS‑P‑E | Same | Same | Same | Same |
| Ruijie RG‑S5360‑48GT4XS‑P‑E | 48 × GE PoE+ + 4 × 10 GE SFP+ | 211 Gbps / 158 Mpps | Up to 1440 W | PoE PSU Redundancy |
| NS‑S5360‑48GT4XS‑P‑E | Same | Same | Same | Same |
Specification Summary
| Parameter | Specification |
|---|---|
| Model | NS‑S5360‑24GT4XS‑P‑E |
| Ports | 24×1 GbE PoE+ RJ45, 4×1/2.5/10 GbE SFP+ uplinks |
| Switching Capacity | 154 Gbps |
| Forwarding Rate | 115 Mpps |
| PoE+ Budget | Up to 740 W (using dual PSU) |
| Power Supply Slots | 2 × pluggable modules, redundancy when supported |
| Power Consumption | ≤35 W (idle), ≤810 W (full PoE) |
| Operating Temp. | 0 °C to +45 °C (standard) / –40 °C to +65 °C (industrial config) |
| Dimensions | 442×420×43.6 mm, ~4.2 kg |
| Protection | Nano‑coating, 10 kV surge, IP40 |
| Management & OS | SNMP/Web/CLI/Telnet/TR‑069 via Ruijie INC/cloud |
