NSComm S5360-24GT4XS-E 24x1G & 4x10G SFP+ L3 Managed Switch
NS‑S5360‑24GT4XS‑E, 24×1 Gbps RJ45 + 4×10 Gbps SFP+ Layer 2+ Fiber Switch
As a trusted OEM partner alongside Cisco, H3C, Huawei, and Ruijie, NSComm offers exactly the same hardware, firmware (RGOS 12.X), and industrial‑grade reliability of Ruijie’s RG‑S5360‑24GT4XS‑E under your brand label.
Our NS‑S5360‑E series delivers enterprise‑grade Layer 3 routing, virtualization (VSU), robust security, and flexibility of uplinks and PoE configurations across 24‑port and 48‑port models.
Overview
The NS‑S5360‑24GT4XS‑E features 24 × 1 Gbps RJ45 downlinks and 4 × 1/2.5/10 Gbps SFP+ uplinks (combo), with 154 Gbps switching capacity and 115 Mpps forwarding rate. Built for campus edge or distribution layers requiring high reliability and throughput.
Highlights
-
154 Gbps / 115 Mpps forwarding under full load
-
24×1 GbE downlink + 4×1/2.5/10 GbE SFP+ uplinks with flexible backbone options
-
Supports advanced Layer 2+ features: VLAN/QinQ, RLDP, ERPS, ACLs, IPv4/IPv6 support
-
Supports VSU virtualization for sub‑50 ms failover and simplified management
-
Nano‑coating, wide temperature range (–40 °C to +65 °C), and 10 kV surge protection for deployment in harsh environments
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS‑PA70IB | AC Power Module | 70 W AC PSU for NS‑S5360‑24GT4XS‑E deployments |
| NS‑PA600I‑P‑F | AC Power Module | 600 W PSU for high‑load or PoE scenarios |
| NS‑PA1000I‑P‑F | AC Power Module | 1000 W AC PSU for larger redundancy setups |
| NS‑XG‑SFP‑SR | SFP+ Transceiver | 10 G SR module (850 nm, multimode) |
| NS‑RMK‑1U | Rack Mount Kit | 19″ 1U mounting brackets |
Compare with Similar Models
| Model | Ports & Uplinks | Capacity / Forwarding | PoE+ Budget | Power Redundancy |
|---|---|---|---|---|
| Ruijie RG‑S5360‑24GT4XS‑E | 24 × GE + 4 × 10 GE SFP+ | 154 Gbps / 115 Mpps | None | Dual hot-swap PSUs |
| NS‑S5360‑24GT4XS‑E | Same | Same | None | Same |
| Ruijie RG‑S5360‑48GT4XS‑E | 48 × GE + 4 × 10 GE SFP+ | 211 Gbps / 158 Mpps | None | Dual PSUs |
| NS‑S5360‑48GT4XS‑E | Same | Same | None | Same |
| Ruijie RG‑S5360‑24GT4XS‑P‑E | 24 × GE PoE+ + 4 × 10 GE SFP+ | 154 Gbps / 115 Mpps | Up to 740 W | PoE PSU Redundancy |
| NS‑S5360‑24GT4XS‑P‑E | Same | Same | Same | Same |
| Ruijie RG‑S5360‑48GT4XS‑P‑E | 48 × GE PoE+ + 4 × 10 GE SFP+ | 211 Gbps / 158 Mpps | Up to 1440 W | PoE PSU Redundancy |
| NS‑S5360‑48GT4XS‑P‑E | Same | Same | Same | Same |
Specification Summary
| Parameter | Specification |
|---|---|
| Model | NS‑S5360‑24GT4XS‑E |
| Ports | 24×1 GbE RJ45 downlinks, 4×1/2.5/10 GbE SFP+ uplinks |
| Switching Capacity | 154 Gbps |
| Forwarding Rate | 115 Mpps |
| MAC Table Size | 16,000 entries |
| ARP Table Size | 4,000 entries |
| IPv4 Unicast Routes | ~6,000 |
| Power Supply Slots | 2 × pluggable modules, 1+1 redundancy |
| Power Consumption | ≤25 W (no load), ≤30 W (peak) |
| Operating Temp. | –40 °C to +65 °C |
| Dimensions (W×D×H) | 442 × 420 × 43.6 mm |
| Weight | ~4.4 kg |
| Protection | Nano‑coating, IP40, 10 kV surge resistance |
| Management & OS | SNMP/Web/CLI/Telnet/USB/TR‑069 (INC/cloud) |
