NSComm S5000-24GT4MS-P-E 24x1G (PoE+) & 4x1G/2.5G SFP PoE Switch
NS‑S5000‑24GT4MS‑P‑E, 24 Gigabit Ports, 4 × 1/2.5 Gbps SFP, PoE+
As a trusted manufacturer alongside Cisco, H3C, Huawei, and Ruijie, NSComm delivers identical hardware and performance under your own brand.
Our NS‑S5000 series fully matches Ruijie RG‑S5000‑E models—featuring the same port configurations, surge protection, uplink speeds, L2+ routing, PoE capabilities, and enterprise‑grade reliability.
Overview
Adds PoE capability to 24‑port variant. Supports 802.3af/at PoE up to 370 W total budget. Same L2+/static routing, surge protection, RLDP, energy-saving. Matches Ruijie RG‑S5000‑24GT4MS‑P‑E.
Highlights
-
Combines PoE+ support (IEEE 802.3af/at) across all 24 ports with 370 W total budget for high-density deployments.
-
2.5 GbE uplinks ensure high uplink capacity and clean burst-handling of video and data traffic.
-
Features LLDP, RLDP, CPP, ERPS loop detection, and 10 kV surge protection for resilient network operation.
-
Smart PoE management with scheduling, power priority, and hot-warm standby to maintain uptime.
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS‑PA370‑PoE | PoE Power Module | 370 W power supply with PoE capability |
| NS‑SFP‑1G‑SX | SFP Transceiver | 1 Gbps multimode fiber |
| NS‑SFP‑1G‑LX | SFP Transceiver | 1 Gbps single-mode fiber |
| NS‑SFP‑2.5G‑04 | SFP Transceiver | 2.5 Gbps uplink support |
| NS‑RMK‑1U | Rack Mount Kit | 1U mounting bracket |
| NS‑Console‑Cable | Console Cable | RJ45 management console cable |
Compare with Similar Models
| Model | Ports (Access / Uplink) | PoE Support | Capacity | Forward Rate | Key Features |
|---|---|---|---|---|---|
| Ruijie RG‑S5000‑10GT2MS‑E | 10 × 1 GbE, 2 × 2.5 GbE SFP | None | 36 Gbps | ~27 Mpps | L2+, RLDP, 10 kV protection |
| NS‑S5000‑10GT2MS‑E | Same | None | Same | Same | Same specs under your brand |
| Ruijie RG‑S5000‑10GT2MS‑P‑E | 10 × 1 GbE (8 PoE+), 2× SFP | PoE+ (125 W) | 36 Gbps | ~27 Mpps | L2+, PoE+, RLDP, surge protect |
| NS‑S5000‑10GT2MS‑P‑E | Same | Same | Same | Same | Brand equivalent PoE model |
| Ruijie RG‑S5000‑24GT4MS‑E | 24 × 1 GbE, 4 × 2.5 GbE SFP | None | ~68 Gbps | ~51 Mpps | High-density, fanless, L2+/RIP |
| NS‑S5000‑24GT4MS‑E | Same | None | Same | Same | Voice identical, brand-labeled |
| Ruijie RG‑S5000‑48GT4MS‑E | 48 × 1 GbE, 4 × 2.5 GbE SFP | None | ~139 Gbps | ~104 Mpps | Larger port count, high throughput |
| NS‑S5000‑48GT4MS‑E | Same | None | Same | Same | Equivalent 48‑port version |
| Ruijie RG‑S5000‑24GT4MS‑P‑E | 24 × 1 GbE PoE+, 4×2.5 GbE SFP | PoE+ (370 W) | ~68 Gbps | ~51 Mpps | High-power PoE, RLDP, L2+, surge protect |
| NS‑S5000‑24GT4MS‑P‑E | Same | Same | Same | Same | PoE budget high, under your label |
Specification Summary
| Parameter | Specification |
|---|---|
| Model | NS‑S5000‑24GT4MS‑P‑E |
| Downlink Ports | 24 × 10/100/1000 BASE‑T (PoE/PoE+ supported) |
| Uplink Ports | 4 × 1 GbE / 2.5 GbE SFP |
| PoE Standard | IEEE 802.3af/at |
| PoE Budget | 370 W total |
| Switching Capacity | ~68 Gbps |
| Forwarding Rate | ~51 Mpps |
| MAC Table | 16,000 entries |
| Routing Support | Static, RIP / RIPng |
| Surge Protection | Common-mode 10 kV |
| RLDP / ERPS | Supported |
| Operating Temperature | 0–45 °C |
| Noise | ≤ 40 dB |
| Dimensions | 440 × 220 × 43.6 mm (1 U) |
| Weight | ~2.8 kg |
| Management | CLI / Web GUI / SNMP / Cloud |
