NSComm S5000-24GT4MS-E 24x1G & 4x1G/2.5G SFP L2+ Managed Switch
NS‑S5000‑24GT4MS‑E, 24 Gigabit Ports + 4 × 1/2.5 Gbps SFP Uplinks (non‑PoE)
As a trusted manufacturer alongside Cisco, H3C, Huawei, and Ruijie, NSComm delivers identical hardware and performance under your own brand.
Our NS‑S5000 series fully matches Ruijie RG‑S5000‑E models, featuring the same port configurations, surge protection, uplink speeds, L2+ routing, PoE capabilities, and enterprise‑grade reliability.
Overview
L2+ access switch with 24 × 1 GbE downlinks, 4 × 1/2.5 GbE SFP uplinks. Supports static routing, RLDP, port protection, intelligent energy-saving, and fanless/no‑fan operation. Equivalent to RG‑S5000‑24GT4MS‑E.
Highlights
-
Switching capacity up to 82 Gbps and forwarding rate 61 Mpps, ideal for mid‑size campus or enterprise workloads.
-
2.5 GbE uplinks provide higher bandwidth and improved uplink performance in high-data scenarios.
-
Comprehensive protection: 10 kV surge, CPP, RLDP, ERPS loop prevention ensure network resilience.
-
Advanced L2+ features: VLAN, QoS, STP/RSTP/MSTP, ERPS ensure reliable traffic management.
-
Plug-and-play deployment via cloud/on-site WIS systems simplifies device registration, batch configuration, and zero-touch replacements.
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS‑PA240‑48 | Power Supply Unit | Fixed AC power module, 100–240 V |
| NS‑SFP‑1G‑SX | SFP Transceiver | 1 Gbps MMF fiber module |
| NS‑SFP‑1G‑LX | SFP Transceiver | 1 Gbps SMF fiber |
| NS‑SFP‑2.5G‑04 | SFP Transceiver | 4-port 2.5 Gbps fiber uplink support |
| NS‑RMK‑1U | Rack Mount Kit | 1U installation bracket |
| NS‑Console‑Cable | Console Cable | RJ45 console cable |
Compare with Similar Models
| Model | Ports (Access / Uplink) | PoE Support | Capacity | Forward Rate | Key Features |
|---|---|---|---|---|---|
| Ruijie RG‑S5000‑10GT2MS‑E | 10 × 1 GbE, 2 × 2.5 GbE SFP | None | 36 Gbps | ~27 Mpps | L2+, RLDP, 10 kV protection |
| NS‑S5000‑10GT2MS‑E | Same | None | Same | Same | Same specs under your brand |
| Ruijie RG‑S5000‑10GT2MS‑P‑E | 10 × 1 GbE (8 PoE+), 2× SFP | PoE+ (125 W) | 36 Gbps | ~27 Mpps | L2+, PoE+, RLDP, surge protect |
| NS‑S5000‑10GT2MS‑P‑E | Same | Same | Same | Same | Brand equivalent PoE model |
| Ruijie RG‑S5000‑24GT4MS‑E | 24 × 1 GbE, 4 × 2.5 GbE SFP | None | ~68 Gbps | ~51 Mpps | High-density, fanless, L2+/RIP |
| NS‑S5000‑24GT4MS‑E | Same | None | Same | Same | Voice identical, brand-labeled |
| Ruijie RG‑S5000‑48GT4MS‑E | 48 × 1 GbE, 4 × 2.5 GbE SFP | None | ~139 Gbps | ~104 Mpps | Larger port count, high throughput |
| NS‑S5000‑48GT4MS‑E | Same | None | Same | Same | Equivalent 48‑port version |
| Ruijie RG‑S5000‑24GT4MS‑P‑E | 24 × 1 GbE PoE+, 4×2.5 GbE SFP | PoE+ (370 W) | ~68 Gbps | ~51 Mpps | High-power PoE, RLDP, L2+, surge protect |
| NS‑S5000‑24GT4MS‑P‑E | Same | Same | Same | Same | PoE budget high, under your label |
Specification Summary
| Parameter | Specification |
|---|---|
| Model | NS‑S5000‑24GT4MS‑E |
| Downlink Ports | 24 × 10/100/1000 BASE‑T |
| Uplink Ports | 4 × 1 GbE/2.5 GbE SFP |
| Switching Capacity | ~68 Gbps |
| Forwarding Rate | ~51 Mpps |
| MAC Table | 16,000 entries |
| Routing Support | Static routing, RIP/RIPng |
| VLAN Support | Up to 4,096 VLANs |
| Surge Protection | Common‑mode 10 kV |
| RLDP / ERPS | Supported |
| Operating Temp | 0–45 °C |
| Noise | ≤ 40 dB (fanless or low‑noise design) |
| Dimensions (W×D×H) | 440 × 220 × 43.6 mm (1 U) |
| Weight | ~2.8 kg |
| Management | CLI, Web GUI, SNMP, Syslog, Cloud |
