NSComm S5000-10GT2MS-P-E 8x1G (PoE+) & 2x2.5G SFP PoE Switch
NS‑S5000‑10GT2MS‑P‑E, 10 Gigabit Ports + 2 × 2.5 Gbps SFP + PoE+
As a trusted manufacturer alongside Cisco, H3C, Huawei, and Ruijie, NSComm delivers identical hardware and performance under your own brand.
Our NS‑S5000 series fully matches Ruijie RG‑S5000‑E models, featuring the same port configurations, surge protection, uplink speeds, L2+ routing, PoE capabilities, and enterprise‑grade reliability.
Overview
Everything as above, plus IEEE 802.3af/at PoE support on 8 downlink ports (up to 125 W total). Perfect for powering IP cameras or wireless APs. Equivalent to Ruijie RG‑S5000‑10GT2MS‑P‑E.
Highlights
-
2.5 GbE uplinks eliminate gigabit bottlenecks—support smooth burst data transfer and greater terminal density.
-
Industry‑leading 10 kV surge protection on each port for robust performance in harsh environments.
-
Proprietary CPU Protection Policy (CPP) safeguards device control planes from DOS attacks and abnormal traffic.
-
Rapid Link Detection Protocol (RLDP) quickly detects and isolates network loops to prevent broadcast storms.
-
Fanless, compact design with Energy‑Efficient Ethernet (EEE) support ensures ultra‑quiet and low‑power operation suitable for offices.
-
IEEE 802.3af/at PoE support (8 ports) with 125 W budget, ideal for powering devices like APs and cameras.
-
PoE scheduling, port priority, and hot‑start resilience deliver intelligent power management.
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS‑PA240‑PoE | PoE Power Module | External AC module supporting 125 W PoE power |
| NS‑SFP‑1G‑SX | SFP Transceiver | 1 Gbps MMF fiber |
| NS‑SFP‑1G‑LX | SFP Transceiver | 1 Gbps SMF fiber |
| NS‑SFP‑2.5G‑02 | SFP Transceiver | 2.5 Gbps fiber uplink |
| NS‑RMK‑1U | Rack Mount Kit | 1U bracket kit |
| NS‑Console‑Cable | Console Cable | RJ45 console management cable |
Compare with Similar Models
| Model | Ports (Access / Uplink) | PoE Support | Capacity | Forward Rate | Key Features |
|---|---|---|---|---|---|
| Ruijie RG‑S5000‑10GT2MS‑E | 10 × 1 GbE, 2 × 2.5 GbE SFP | None | 36 Gbps | ~27 Mpps | L2+, RLDP, 10 kV protection |
| NS‑S5000‑10GT2MS‑E | Same | None | Same | Same | Same specs under your brand |
| Ruijie RG‑S5000‑10GT2MS‑P‑E | 10 × 1 GbE (8 PoE+), 2× SFP | PoE+ (125 W) | 36 Gbps | ~27 Mpps | L2+, PoE+, RLDP, surge protect |
| NS‑S5000‑10GT2MS‑P‑E | Same | Same | Same | Same | Brand equivalent PoE model |
| Ruijie RG‑S5000‑24GT4MS‑E | 24 × 1 GbE, 4 × 2.5 GbE SFP | None | ~68 Gbps | ~51 Mpps | High-density, fanless, L2+/RIP |
| NS‑S5000‑24GT4MS‑E | Same | None | Same | Same | Voice identical, brand-labeled |
| Ruijie RG‑S5000‑48GT4MS‑E | 48 × 1 GbE, 4 × 2.5 GbE SFP | None | ~139 Gbps | ~104 Mpps | Larger port count, high throughput |
| NS‑S5000‑48GT4MS‑E | Same | None | Same | Same | Equivalent 48‑port version |
| Ruijie RG‑S5000‑24GT4MS‑P‑E | 24 × 1 GbE PoE+, 4×2.5 GbE SFP | PoE+ (370 W) | ~68 Gbps | ~51 Mpps | High-power PoE, RLDP, L2+, surge protect |
| NS‑S5000‑24GT4MS‑P‑E | Same | Same | Same | Same | PoE budget high, under your label |
Specification Summary
| Parameter | Specification |
|---|---|
| Model | NS‑S5000‑10GT2MS‑P‑E |
| Port Configuration | 10 × 10/100/1000 BASE‑T (8 PoE+) + 2 × 2.5 GbE SFP |
| PoE Standard | IEEE 802.3af/at |
| PoE Budget | 125 W total |
| Switching Capacity | 36 Gbps |
| Forwarding Rate | ~27 Mpps |
| MAC Table | 16,000 entries |
| Routing Support | Static, RIP |
| Surge Protection | 10 kV port protection |
| RLDP / ERPS | Yes |
| Operating Temp | 0–45 °C |
| Power Consumption | ~141 W (including PoE) |
| Dimensions | 297 × 170 × 43.6 mm (1 U) |
| Weight | ~2.5 kg |
| Management | CLI / Web / SNMP / Cloud‑ready |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Certified Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your NSComm products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
