Ruijie RG-MAP920-SF-M Indoor Wi-Fi 7 Optical Micro AP, 3.57 Gbps, SOE Solution
Ruijie RG-MAP920-SF-M Wireless Access Point
The Ruijie RG-MAP920-SF-M is a compact, wall-mounted wireless access point, purpose-built for hotel rooms, dormitories, apartments, and other indoor environments requiring discreet, in-room wireless coverage.
Featuring dual-band 802.11ac Wave 2 technology, built-in Gigabit LAN ports, and Power over Ethernet (PoE) support, this AP enables seamless HD video streaming, low-latency browsing, and integrated wired access for IPTV or VoIP devices.
With easy deployment and enterprise-grade manageability, the MAP920-SF-M is an ideal choice for space-constrained scenarios requiring reliable wireless and wired connectivity.
Overview
Highlights
-
Wall Plate Design: Slim, in-wall form factor matches standard 86 mm wall boxes—ideal for hotel rooms, residences, or classrooms.
-
Dual-Band AC Performance: Supports simultaneous 2.4GHz and 5GHz with 802.11ac Wave 2, delivering up to 1.167 Gbps wireless throughput.
-
Multiple LAN Ports: Includes 3 × 10/100/1000 Mbps Ethernet ports for wired device access such as IP phones, IPTV, or desktops.
-
Enterprise Integration: Supports VLAN, 802.1X authentication, and centralized management via Ruijie Cloud or controllers.
-
Seamless Roaming: Supports Layer 2/3 fast roaming for mobile users moving between rooms or zones.
-
High Security: Includes WPA3 security, rogue AP detection, access control lists (ACL), and ARP spoofing protection.
-
Easy Deployment: Powered via 802.3af PoE, eliminating the need for local power adapters.
-
Zero-Touch Provisioning: Supports plug-and-play deployment and cloud-based configuration, simplifying large-scale rollouts.
Recommended Accessories
| Product Model | Category | Description |
|---|---|---|
| RG-POE120-15W | PoE Injector | 802.3af PoE injector, 15.4W output, suitable for wall APs |
| AP-INBOX-FLUSH | Mounting Box | Wall mount flush box for recessed installation |
| RG-EG2100-P V2 | Cloud Gateway | Gigabit cloud-managed security gateway for small networks |
| SFP-GE-LX-SM1310 | SFP Module | 1G SFP, 1310nm single-mode fiber, up to 10km |
Comparison with Similar Wall APs
| Feature | RG-MAP920-SF-M | RG-MAP720-I(W2) | RG-AP820-I(V3) |
|---|---|---|---|
| Wi-Fi Standard | 802.11ac Wave 2 | 802.11ac Wave 2 | 802.11ax (Wi-Fi 6) |
| Max Speed | 1.167 Gbps | 1.167 Gbps | 2.975 Gbps |
| LAN Ports | 3 × 1GE RJ45 | 2 × 1GE RJ45 | 1 × 1GE RJ45 |
| Mounting Type | In-wall (86 mm) | In-wall | Ceiling/Wall |
| PoE Support | 802.3af | 802.3af | 802.3at |
| Target Use Case | Hotels, dorms | Hotels, apartments | SMB office |
Specifications
| Parameter | Specification |
|---|---|
| Model | RG-MAP920-SF-M |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac Wave 2 (Dual-band concurrent) |
| Wireless Throughput | Up to 1.167 Gbps (2.4GHz: 300 Mbps, 5GHz: 867 Mbps) |
| Ethernet Ports | 3 × 10/100/1000 Mbps RJ45 (1 uplink + 2 access + 1 console) |
| PoE Standard | IEEE 802.3af (Class 3) |
| Mounting | 86 mm standard wall box (flush or surface mount) |
| Security Features | WPA3, dynamic VLAN, ARP protection, ACL, WIDS/WIPS |
| Roaming Support | 802.11k/v/r Layer 2/3 fast roaming |
| Management | Ruijie Cloud, RG-MACC, local controller, CLI, SNMP |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Dimensions (W×D×H) | 86 mm × 86 mm × 30 mm |
| Weight | ≤ 0.3 kg |
| Warranty | Limited lifetime warranty |
