Ruijie RG-AP880-AR Indoor Wi-Fi 6 Quad-Radio AP, 8.642 Gbps, All-Optical
Ruijie RG-AP880-AR Wireless Access Point
The Ruijie RG-AP880-AR is a high-performance, Wi-Fi 6 (802.11ax) wireless access point engineered for large-scale enterprise environments, such as offices, campuses, healthcare facilities, and smart classrooms.
Equipped with dual 5.95 Gbps radios, advanced RF optimization, and AI-driven client steering, the AP880-AR delivers high-capacity, low-latency wireless connectivity for dense user scenarios.
Supporting both cloud and on-premise management, it integrates seamlessly into Ruijie’s end-to-end network architecture for unified wired-wireless operations.
Overview
Highlights
-
Wi-Fi 6 Technology: Delivers aggregate speeds of up to 5.95 Gbps using 802.11ax, enabling smoother video, conferencing, and high-bandwidth applications.
-
High-Density Design: Supports up to 1,024 concurrent users, optimized for environments with high user and device density.
-
Dual-Radio Architecture: Features dual-band 2.4GHz (4×4 MIMO) + 5GHz (4×4 MIMO), maximizing throughput and reliability.
-
AI Radio Optimization: Real-time intelligent radio management ensures balanced client load, minimal interference, and dynamic channel selection.
-
OFDMA + MU-MIMO: Supports multi-user transmission technologies to reduce latency and boost spectral efficiency.
-
Seamless Roaming: Enables sub-second Layer 2 & Layer 3 roaming with WPA3 and 802.11k/v/r support.
-
Cloud & On-Premise Management: Compatible with Ruijie Cloud, RG-MACC, or local controllers for flexible deployment models.
-
Security First: Supports WPA3-Enterprise, rogue AP detection, dynamic VLAN assignment, and identity-based access control.
Recommended Accessories
| Product Model | Category | Description |
|---|---|---|
| RG-POE150-54V | PoE Injector | 802.3bt-compliant PoE injector for high-power APs |
| RG-POE-Box | PoE Injector | Gigabit PoE+ power supply box for indoor AP deployments |
| AP-MOUNT-KIT | Mounting Accessory | Ceiling/wall bracket kit for secure AP installation |
| SFP-GE-SX-MM850 | SFP Module | 1G SFP, 850nm, MM fiber, up to 550m |
| RG-EG2100-P V2 | Edge Gateway | Gigabit security gateway with DPI, QoS, and VPN |
Comparison with Similar APs
| Feature | RG-AP880-AR | RG-AP820-I | RG-AP810-I |
|---|---|---|---|
| Wi-Fi Standard | Wi-Fi 6 (802.11ax) | Wi-Fi 6 (802.11ax) | Wi-Fi 5 (802.11ac) |
| Max Speed | 5.95 Gbps | 3.55 Gbps | 1.167 Gbps |
| Radio Chains | 4×4 MIMO (Dual-band) | 2×2 MIMO (Dual-band) | 2×2 MIMO |
| Max Concurrent Clients | 1,024 | 512 | 256 |
| PoE Standard | 802.3bt | 802.3at | 802.3af |
| Best Use Case | High-density enterprise | General office | SMB/Branch office |
Specifications
| Parameter | Specification |
|---|---|
| Model | RG-AP880-AR |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| Dual-Band Radios | 2.4GHz (4×4 MIMO) + 5GHz (4×4 MIMO) |
| Maximum Throughput | 5.95 Gbps total (2.4GHz: 1.15 Gbps, 5GHz: 4.8 Gbps) |
| Ethernet Ports | 1 × 5GE (802.3bt), 1 × GE port |
| PoE Standard | IEEE 802.3bt (Class 6), backward compatible |
| Max Concurrent Clients | 1024+ |
| Antennas | Integrated omnidirectional antennas |
| Security Features | WPA3-Enterprise, WIDS/WIPS, ARP guard, IP/MAC binding |
| Roaming Support | 802.11k/v/r, Layer 2 & 3 fast roaming |
| Mounting | Ceiling, wall, or T-rail mount (kit included) |
| Management | Ruijie Cloud, RG-MACC, local controller, CLI/SNMP |
| Operating Temperature | -10°C to 50°C (14°F to 122°F) |
| Dimensions (W×D×H) | 220 mm × 220 mm × 35 mm |
| Weight | ≤ 1.5 kg |
| Warranty | Limited lifetime warranty |
