Ruijie RG-AP6920-D Outdoor Wi-Fi 7 Dual-Radio AP, 5.95 Gbps Throughput, IP68
Ruijie RG-AP6920-D Wireless Access Point
The Ruijie RG-AP6920-D is a high-performance outdoor Wi-Fi 6 access point, designed for wide-area wireless coverage in challenging environments such as campuses, industrial parks, transport hubs, and smart cities.
With support for the 802.11ax (Wi-Fi 6) standard and a rugged IP68-rated enclosure, the AP6920-D delivers up to 5.95 Gbps wireless throughput and ensures consistent, secure connectivity in all-weather conditions.
Its high-gain antenna design, powerful hardware, and cloud-managed capability make it ideal for large-scale outdoor wireless deployments.
Overview
Highlights
-
Wi-Fi 6 Outdoor Performance: Delivers blazing-fast wireless speeds up to 5.95 Gbps across dual bands with 4×4 MU-MIMO and OFDMA.
-
Rugged IP68 Protection: Fully sealed enclosure resists dust, water, humidity, corrosion, and extreme temperature—ideal for outdoor/industrial use.
-
High Client Density: Supports over 1024 concurrent clients, enabling stable performance in crowded outdoor environments.
-
Flexible Deployment: Includes pole and wall mount options with built-in surge protection and long-range wireless coverage.
-
Secure & Seamless Roaming: Supports 802.11k/v/r Layer 2/3 roaming with WPA3 encryption, rogue AP detection, and RF optimization.
-
PoE++ Powered: Compatible with IEEE 802.3bt (PoE++), simplifying outdoor installations without needing external power.
-
Centralized Management: Works with Ruijie Cloud, RG-MACC platform, or local wireless controllers for simplified provisioning, monitoring, and updates.
-
Industrial-Grade Components: Designed for harsh outdoor conditions with smart cooling and anti-condensation features.
Recommended Accessories
| Product Model | Category | Description |
|---|---|---|
| RG-POE180-60W | PoE Injector | 802.3bt-compliant 60W PoE++ injector for outdoor APs |
| RG-MOUNT-POLE | Mounting Kit | Pole mounting kit with adjustable bracket and screws |
| RG-SFP-GE-LX-SM1310 | SFP Module | 1G SFP, single-mode, 1310nm, up to 10km |
| Outdoor Ethernet Kit | Cable Accessory | Shielded weatherproof Ethernet cable with waterproof glands |
Comparison with Similar Outdoor APs
| Feature | RG-AP6920-D | RG-AP630(IODA2) | RG-AP630(CD) |
|---|---|---|---|
| Wi-Fi Standard | Wi-Fi 6 (802.11ax) | Wi-Fi 6 (802.11ax) | Wi-Fi 5 (802.11ac Wave 2) |
| Max Speed | 5.95 Gbps | 3.55 Gbps | 1.167 Gbps |
| IP Rating | IP68 | IP68 | IP67 |
| Antenna Type | External high-gain | Internal | Internal |
| PoE Standard | 802.3bt | 802.3at | 802.3af |
| Best Use Case | Outdoor high-density | General outdoor campus | SMB outdoor hotspot |
Specifications
| Parameter | Specification |
|---|---|
| Model | RG-AP6920-D |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| Dual-Band Radios | 2.4GHz (4×4 MIMO) + 5GHz (4×4 MIMO) |
| Maximum Throughput | Up to 5.95 Gbps (2.4GHz: 1.15 Gbps, 5GHz: 4.8 Gbps) |
| Ethernet Ports | 1 × 2.5GE PoE++ (802.3bt) + 1 × 1GE |
| PoE Standard | IEEE 802.3bt (PoE++, Class 6) |
| Max Concurrent Clients | 1024+ |
| Enclosure Rating | IP68-rated, outdoor waterproof and dustproof |
| Security Features | WPA3, rogue AP detection, port security, ARP inspection |
| Roaming Support | 802.11k/v/r, Layer 2/3 fast roaming |
| Operating Temperature | -40°C to 65°C (-40°F to 149°F) |
| Antenna Type | External (detachable, high-gain directional/omni options) |
| Mounting Options | Wall or pole mounting |
| Dimensions (W×D×H) | 260 mm × 260 mm × 85 mm |
| Weight | ≤ 2.8 kg |
| Management | Ruijie Cloud, MACC, local controller |
| Warranty | Limited lifetime warranty |
