Ruijie RG-AP820-AR(V3) Indoor Wi-Fi 6 Tri-Radio AP, 5 Gbps SFP i-Share+ Port
Ruijie RG-AP820-AR(V3) Wireless Access Point
The Ruijie RG-AP820-AR(V3) is a cost-effective, high-performance Wi-Fi 6 (802.11ax) wireless access point tailored for small to mid-sized enterprises, schools, retail stores, and office environments.
Equipped with dual-band 2×2 MIMO radios, the AP820-AR(V3) supports up to 2.975 Gbps aggregate wireless throughput. With advanced security, seamless roaming, and centralized management capabilities, it delivers reliable, scalable, and efficient indoor wireless coverage for modern digital workplaces.
Overview
Highlights
-
Wi-Fi 6 Performance: Supports the latest 802.11ax standard with up to 2.975 Gbps total wireless speed for faster downloads and smoother streaming.
-
Compact & Efficient Design: Slim form factor with ceiling-mount capability, ideal for space-constrained deployment scenarios.
-
Dual-Band Radios: Features 2.4GHz (2×2 MIMO) and 5GHz (2×2 MIMO), optimizing client connectivity across both frequency bands.
-
Multi-User Efficiency: OFDMA and MU-MIMO technologies allow simultaneous transmission to multiple devices, reducing network congestion.
-
Seamless Roaming: Supports Layer 2/3 fast roaming with 802.11k/v/r for uninterrupted mobile user experience.
-
Secure Access: Offers WPA3-Enterprise encryption, rogue AP detection, and dynamic VLAN assignment for identity-based security.
-
Flexible Management: Supports Ruijie Cloud, RG-MACC, or on-premise wireless controllers for full lifecycle AP management.
-
Energy-Saving PoE: Compatible with IEEE 802.3at (PoE+), simplifying cabling and reducing installation costs.
Recommended Accessories
| Product Model | Category | Description |
|---|---|---|
| RG-POE120-30W | PoE Injector | 802.3at-compliant 30W Gigabit PoE injector |
| AP-MOUNT-KIT | Mounting Accessory | Universal mounting bracket for ceiling/wall installation |
| SFP-GE-SX-MM850 | SFP Module | 1G SFP, 850nm, MM fiber, up to 550m |
| RG-EG105GW-T | Cloud Gateway | All-in-one security gateway for small office networks |
Comparison with Similar APs
| Feature | RG-AP820-AR(V3) | RG-AP880-AR | RG-AP850-AR(V3) |
|---|---|---|---|
| Wi-Fi Standard | Wi-Fi 6 (802.11ax) | Wi-Fi 6 (802.11ax) | Wi-Fi 6 (802.11ax) |
| Max Speed | 2.975 Gbps | 5.95 Gbps | 3.55 Gbps |
| MIMO Radio Chains | 2×2 MIMO | 4×4 MIMO | 2×2 MIMO |
| Max Concurrent Clients | 512 | 1024 | 512 |
| Mounting Type | Ceiling/Wall | Ceiling | Ceiling |
| PoE Standard | 802.3at | 802.3bt | 802.3at |
| Use Case | SMB / Entry Wi-Fi 6 | High-density enterprise | General office |
Specifications
| Parameter | Specification |
|---|---|
| Model | RG-AP820-AR(V3) |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| Dual-Band Radios | 2.4GHz (2×2 MIMO) + 5GHz (2×2 MIMO) |
| Maximum Throughput | 2.975 Gbps total (2.4GHz: 575 Mbps, 5GHz: 2.4 Gbps) |
| Ethernet Ports | 1 × 1GE RJ45 (PoE+) |
| PoE Standard | IEEE 802.3at (Class 4) |
| Max Concurrent Clients | Up to 512 |
| Antennas | Built-in omnidirectional antennas |
| Security Features | WPA3, rogue AP detection, ARP defense, user isolation |
| Roaming Support | 802.11k/v/r Layer 2/3 fast roaming |
| Mounting Options | Ceiling or wall (bracket included) |
| Management | Ruijie Cloud, RG-MACC, local controller |
| Operating Temperature | -10°C to 50°C (14°F to 122°F) |
| Dimensions (W×D×H) | 180 mm × 180 mm × 33 mm |
| Weight | ≤ 1.1 kg |
| Warranty | Limited lifetime warranty |
