Huawei AirEngine 5773-23WP Wall-Plate Wi-Fi7 AP – 2×2 MIMO, PoE
Huawei AirEngine 5773-23WP: Wi-Fi 7 Wall-Plate AP with 3.57 Gbps Speed, 4 Spatial Streams
The AirEngine 5773‑23WP is a Wi‑Fi 7 (802.11be) wall-plate access point tailored for environments like dormitories, hotels, and compact offices. It features dual-band 2×2 MIMO radios on both 2.4 GHz and 5 GHz, delivering a combined 3.57 Gbps peak throughput.
It includes built-in co-planar smart antennas, hybrid uplink via 2.5 GE electrical uplink (PoE-capable) and multiple GE ports, plus USB/BLE for IoT and O&M.
Overview
Highlights
-
Dual-Band Dual-Radio Wi‑Fi 7
Provides 2.4 GHz (2×2 MIMO) and 5 GHz (2×2 MIMO) with a combined 3.57 Gbps device rate. -
Built-In Intelligent Antennas
Co‑planar smart antennas auto-adjust to suppress interference, reinforce signal strength, and ensure consistent coverage. -
Hybrid Uplink & PoE Power
Delivers flexible uplink via 2.5 GE electrical (PoE-IN) and five GE electrical ports, enabling streamlined cabling. -
IoT & Bluetooth Integration
Includes USB port for ZigBee/RFID expansion and BLE 5.2 for CloudCampus-based commissioning and O&M.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| PoE Injector (802.3at/af) | Power Supply | Supplies PoE over 2.5 GE uplink port |
| 43.2–57.6 V DC Power Adapter | Power Supply | Alternative power source if PoE unavailable |
| Wall/T-Rail Mount Kit | Installation | Included hardware simplifies installation in indoor spaces |
| USB IoT Expansion Module | IoT Integration | Supports ZigBee or RFID peripherals via USB |
| BLE Beacon Module | IoT & Management | Enables Bluetooth-based remote management and location services |
Comparison with Similar Models
| Feature | 5773‑23WP | 5773‑23HW | 5773‑25HW |
|---|---|---|---|
| Wi‑Fi Standard | Wi‑Fi 7 (802.11be) | Wi‑Fi 7 (802.11be) | Wi‑Fi 7 (802.11be) |
| Spatial Streams (MIMO) | 2×2 + 2×2 = 4 streams | 2×2 + 2×2 = 4 streams | 2×2 + 2×2 = 4 streams |
| Peak Device Throughput | 3.57 Gbps | 3.57 Gbps | 3.00 Gbps |
| Smart Antennas | Built-in co-planar | Built-in co-planar | Built-in standard |
| Uplink Ports | 2.5 GE elect.(PoE-IN) + 5×GE elect | 2.5 GE elect.(PoE-IN) + 4×GE | 2×2.5 GE electrical |
| IoT/Bluetooth Support | USB + BLE 5.2 | USB + BLE 5.4 | USB + BLE 5.4 |
| Ideal Deployment | Premium rooms, dorms | Economy rooms, hotels | Standard hotels, SMB spaces |
Specifications
| Parameter | Specification |
|---|---|
| Wi‑Fi Standard | IEEE 802.11a/b/g/n/ac/ax/be (Wi‑Fi 7 with backward support) |
| Spatial Streams (MIMO) | 2.4 GHz 2×2; 5 GHz 2×2; total 4 streams |
| Peak Device Throughput | 3.57 Gbps (689 Mbps @2.4 GHz + 2.88 Gbps @5 GHz) |
| Antenna | Built-in co‑planar smart antennas; 3 dBi each band |
| Port Configuration | 1×2.5 GE electrical uplink (PoE-In); 5×GE downlinks; 1×USB |
| Power Input | PoE (IEEE 802.3bt/at) or DC 43.2–57.6 V |
| Max Power Consumption | 14.2 W (excl. USB) |
| Dimensions (H × W × D) | 185 × 86 × 45 mm |
| Weight | 0.41 kg |
| Operating Temp / Humidity | 0 °C to +40 °C; 5–95 % RH; altitude –60 m to +5000 m |
| BLuetooth / IoT Support | BLE 5.2 for O&M; USB for IoT modules |
| Security & QoS Features | WPA3, 802.1X, WIPS/WIDS, ACL, WMM, bandwidth management, SST, MLO, MU‑MIMO, OFDMA |
| Certifications | WPA3, CE, FCC, RoHS, IEEE standards compliance |
