Huawei AirEngine 5773-23HW Wall-Plate Wi-Fi7 AP – 4×4 MIMO, PoE
Huawei AirEngine 5773-23HW: Wi-Fi 7 Wall-Plate AP with 3.57 Gbps, 4 Spatial Streams
The AirEngine 5773‑23HW is Huawei’s wall-plate Wi‑Fi 7 (802.11be) access point, ideal for environments such as dormitories, hotels, offices, and small spaces.
Featuring dual-band 2×2 MIMO (2.4/5 GHz) with four spatial streams, it achieves up to 3.57 Gbps device throughput. It supports hybrid uplink and PoE over both optical and electrical ports, built-in smart antennas, IoT expansion, and BLE management.
Overview
Highlights
-
Dual-Band 2×2 MIMO Wi‑Fi 7
2.4 GHz and 5 GHz radios deliver a combined device rate up to 3.57 Gbps (0.69 + 2.88 Gbps) -
Smart Antenna Technology
Built-in co-planar smart antennas auto-adjust to suppress interference and enhance coverage. -
Hybrid Optical-Electrical Uplink
Includes 2.5 GE optical uplink (with embedded optical module and hybrid cable support for 2 km PoE) plus 1 GE electrical uplink. -
Compact & Expandable IoT Support
Wall-plate form factor with USB for ZigBee/RFID and BLE 5.2 for O&M; supports Fit/Fat/Cloud modes.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| PoE Injector (802.3at/af) | Power Supply | Provides PoE over 2.5 GE electrical port |
| 12 V DC Power Adapter | Power Supply | Supports DC input alternative |
| Wall/T-Rail Mount Kit | Installation | Included for mounting in rooms |
| USB IoT Modules | Expansion | For ZigBee/RFID compatibility |
Comparison with Similar Models
| Feature | 5773‑23HW | 5773‑23H | 5773‑25HW |
|---|---|---|---|
| Wi‑Fi Standard | Wi‑Fi 7 (802.11be) | Wi‑Fi 7 (802.11be) | Wi‑Fi 7 (802.11be) |
| Bands & MIMO Streams | 2×2 + 2×2 (4 streams) | Same | Same |
| Peak Device Rate | 3.57 Gbps | 3.57 Gbps | 3.00 Gbps |
| Uplink Ports | Optical 2.5 GE + 1 GE | Optical 2.5 GE + 1 GE | 2×2.5 GE electrical |
| Smart Antenna | Yes | Yes | No |
| Ideal Use Cases | Dorms, hotels, SMB rooms | Same | Standard hotel rooms |
Specifications
| Parameter | Specification |
|---|---|
| Wi‑Fi Standard | IEEE 802.11be (Wi‑Fi 7) |
| Spatial Streams (MIMO) | 2.4 GHz: 2×2; 5 GHz: 2×2 = 4 streams |
| Max Device Rate | 3.57 Gbps (0.69 + 2.88 Gbps) |
| Antenna | Built-in co‑planar smart antennas |
| Radios | Dual-band: 2.4 & 5 GHz |
| Uplink Ports | 2.5 GE optical (hybrid PoE); 1 GE electrical |
| Downlink Ports | USB (IoT/BLE) |
| Power Input | PoE (802.3at/af) or 12 V DC |
| Smart Antenna | Yes |
| MLO & MRU Support | Yes |
| Bluetooth | BLE 5.2 |
| Max Users | Up to 1,200 (600 per radio) |
| Dimensions (H×W×D) | 160 × 86 × 38 mm |
| Operating Temp | 0 °C to +40 °C |
