Huawei AirEngine 5762C-17W-V2 Wi-Fi 6 AP, 160 MHz, 2.975 Gbps
Huawei AirEngine 5762C-17W Wall-Plate Wi-Fi 6 AP Overview
The AirEngine 5762C‑17W‑V2 is a high-performance Wi‑Fi 6 (802.11ax) wall-plate access point optimized for dense environments such as hotels, hospitals, dormitories, and villas.
It features built-in co-planar smart antennas, delivers dual-band 2×2 MIMO performance with a total throughput of 2.975 Gbps, and offers versatile connectivity through multiple Ethernet ports.
Highlights
-
Dual-Band 2×2 MIMO (4 spatial streams)
• 2.4 GHz (2×2): up to 0.575 Gbps
• 5 GHz (2×2) with 160 MHz support: up to 2.4 Gbps
• Combined: 2.975 Gbps -
Co-Planar Smart Antennas
Antenna array automatically enhances signal strength, doubles gain, and widens coverage by ~20% for reliable, interference-free connectivity. -
Rich Port Ensemble
Includes:
• 1× GE uplink (PoE‑in capable)
• 4× GE downlink ports to eliminate bottlenecks
• USB port for IoT expansion
• Built-in BLE for CloudCampus O&M integration -
Comprehensive Wi‑Fi 6 Features
Supports MU‑MIMO, OFDMA, 1024‑QAM, BSS Coloring, SST, TWT, RSSI-based roaming, and more—ideal for high-density, low-latency environments. -
Flexible Deployment Modes
Operates in Fit, Fat, and Cloud modes to integrate into a diverse range of management systems.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| PoE Injector (IEEE 802.3af) | Power Supply | Supports the GE uplink with PoE-In for clean, cable-free deployment |
| 12 V DC Power Adapter | Power Supply | Alternative DC power option where PoE is unavailable |
| Wall Ceiling/T-Rail Mount Kit | Installation | Included brackets and screws for easy installation in wall or ceiling environments |
Comparison with Similar Models
| Feature | 5762C‑17W‑V2 | 5762C‑10‑V2 | 5761‑11W |
|---|---|---|---|
| Wi‑Fi Standard | Wi‑Fi 6 (802.11ax) | Wi‑Fi 6 | Wi‑Fi 6 |
| Spatial Streams (MIMO) | 2×2 + 2×2 = 4 | 2×2 + 2×2 = 4 | 2×2 + 2×2 = 4 |
| Peak Device Rate | 2.975 Gbps | 2.975 Gbps | 1.775 Gbps |
| Smart Antennas | Co-planar smart antennas | Co-planar smart antennas | Standard built-in antennas |
| Uplink Port | 1× GE (PoE-in) | 1× GE (PoE-in) | 1× GE (PoE-in) |
| Downlink Ports | 4× GE | 4× GE | 4× GE |
| Ideal Use Case | Hotels, dorms, villas | Classrooms, small offices | Budget venues, SMB spaces |
Specifications
| Parameter | Specification |
|---|---|
| Wi‑Fi Standard | IEEE 802.11a/b/g/n/ac/ax (Wi‑Fi 6) |
| Spatial Streams | 2.4 GHz: 2×2; 5 GHz: 2×2 = 4 streams |
| Peak Device Throughput | 2.975 Gbps (0.575 + 2.4 Gbps) |
| Antennas | Built-in co-planar smart antennas; 2.5 dBi @2.4 GHz / 3 dBi @5 GHz each chain |
| Uplink / Downlink Ports | 1× GE RJ45 (PoE-in), 4× GE RJ45; USB for IoT expansion |
| Power Input | IEEE 802.3af PoE-in or 12 V DC |
| Max Power Consumption | 9.4 W typical |
| Dimensions | 160 × 86 × 38 mm |
| Weight | ~0.30 kg |
| Operating Conditions | 0 °C to +40 °C; 5–95 % RH non-condensing; –60 m to 5,000 m altitude |
| Advanced Features | MU‑MIMO, OFDMA, 1024‑QAM, BSS Coloring, SST, TWT |
| Security & Management | WPA3, 802.1X, ACL, WIPS/WIDS, VLAN tagging, Fit/Fat/Cloud modes |
