NSComm NS-SFP-10G-SR 10G Base-SR SFP+ 850nm 300m Duplex LC MMF DDM Optical Transceiver Module
NS-SFP-10G-SR Transceiver Module | 10Gbps, 850nm, Duplex LC, 300m ā Compatible with allĀ brands
Overview
The NSComm NS-SFP-10G-SR is a high-performance Small Form-Factor Pluggable (SFP+) transceiver module designed for 10 Gigabit Ethernet applications. It operates over multimode fiber (MMF) with a wavelength of 850nm, supporting link distances of up to 300 meters using OM3 fiber and up to 400 meters using OM4 fiber, via a duplex LC connector.
This module is hot-swappable, enabling easy installation and maintenance without disrupting network operations. It is compliant with the SFP+ Multi-Source Agreement (MSA) and supports Digital Optical Monitoring (DOM) for real-time diagnostics.
The NS-SFP-10G-SR is compatible across all brands, ensuring broad interoperability with a wide range of networking equipment, including but not limited to major brands like Cisco, Juniper, Arista, and more.
Compatible Brands
The NS-SFP-10G-SRĀ is universally compatible across all brands. If you need to verify compatibility with your specific switch model, please click Contact Us Now for assistance.
Key Specifications
| Specification | Details |
|---|---|
| Vendor Name | NSComm |
| Form Factor | SFP+ (Small Form-Factor Pluggable) |
| Max. Data Rate | 10.31 Gbps |
| Wavelength | 850nm |
| Max. Cable Distance | 300m over OM3 MMF / 400m over OM4 MMF |
| Connector | Duplex LC |
| Optical Components | VCSEL 850nm |
| Media | MMF (Multimode Fiber) |
| DOM Support | Yes |
| TX Power | -7.3 ~ -1.2 dBm |
| Receiver Sensitivity | < -9.9 dBm |
| Industrial Temperature Range | 0Ā°C to 70Ā°C (Commercial) |
| Protocols | IEEE 802.3ae, SFF-8431, SFP+ MSA |
