NSComm NS-SFP-10G-LR 10G Base SFP+ 1310nm 10km Duplex LC SMF DDM Optical Transceiver Module
NS-SFP-10G-LR Transceiver Module | 10Gbps, 1310nm, Single-Mode LC, 10km – Compatible with all brands
Overview
The NSComm NS-SFP-10G-LR is a high-performance Small Form-Factor Pluggable (SFP+) transceiver module designed for 10 Gigabit Ethernet applications. It operates over single-mode fiber (SMF) with a wavelength of 1310nm, supporting link distances of up to 10 kilometers using a duplex LC connector.
This module is hot-swappable, enabling easy installation and maintenance without disrupting network operations. It is compliant with the SFP+ Multi-Source Agreement (MSA) and supports Digital Optical Monitoring (DOM) for real-time diagnostics.
The NS-SFP-10G-LR is compatible across all brands, ensuring broad interoperability with a wide range of networking equipment, including but not limited to major brands like Cisco, Juniper, Arista, and more.
Compatible Brands
The NS-SFP-10G-LR is universally compatible across all brands. If you need to verify compatibility with your specific switch model, please click Contact Us Now for assistance.
Key Specifications
| Specification | Details |
|---|---|
| Vendor Name | NSComm |
| Form Factor | SFP+ (Small Form-Factor Pluggable) |
| Max. Data Rate | 10.31 Gbps |
| Wavelength | 1310nm |
| Max. Cable Distance | 10km over SMF |
| Connector | Duplex LC |
| Optical Components | DFB Laser / PIN Photodiode |
| Media | SMF (Single-Mode Fiber) |
| DOM Support | Yes |
| TX Power | -8.2 ~ 0.5 dBm |
| Receiver Sensitivity | < -14.0 dBm |
| Industrial Temperature Range | 0°C to 70°C (Commercial) |
| Protocols | IEEE 802.3ae, SFF-8431, SFP+ MSA |
