NSComm NS-QSFP28-100G-DR 100G Base-DR QSFP28 Single Lambda 1310nm 500m Duplex LC SMF DOM Optical Transceiver Module
NS-QSFP28‑100G‑DR Optical Transceiver Module | 100 Gbps, 1310 nm, Duplex LC, 500 m – Multi Brands Compatible
Product Overview
The NSComm NS-QSFP28-100G-DR is a high-efficiency, single‑wavelength 100 Gigabit Ethernet optical module tailored for 500 m connectivity over single-mode fiber. Leveraging PAM4 encoding at 1310 nm, it consolidates four 25 Gbps NRZ electrical lanes into one optical signal.
Featuring a duplex LC connector and full support for Digital Diagnostic Monitoring (DDM/DOM), it enables effortless hot-swappable installation and live performance monitoring. The module adheres to QSFP28 MSA and IEEE 802.3cd standards.
Designed for universal compatibility, it works seamlessly with equipment from major brands including Cisco, Juniper, Arista, Dell, Huawei, HPE Aruba, and more.
Compatible Brands
The NS-QSFP28-100G-DR is universally compatible across all brands. If you need to verify compatibility with your specific switch model, please click Contact Us Now for assistance.
Key Specifications
| Specification | Details |
|---|---|
| Vendor Name | NSComm |
| Form Factor | QSFP28 |
| Max. Data Rate | 100 Gbps (single-lambda PAM4) |
| Wavelength | ~1310 nm (1304.5–1317.5 nm) |
| Max. Cable Distance | Up to 500 m over SMF G.652 fiber |
| Connector | Duplex LC |
| Optical Components | Cooled EML transmitter, PIN photodiode receiver |
| Media Type | Single-Mode Fiber (SMF) |
| Digital Diagnostic Monitoring | Supported |
| Forward Error Correction | Host-side FEC (IEEE 802.3cd) |
| Transmit Power (per lane) | –2.4 to +4.0 dBm |
| Receiver Sensitivity | Typically < –5.4 dBm |
| Power Consumption | ≤ 4.5 W |
| Operating Temperature | 0 °C to 70 °C (Standard) |
| Protocol Compliance | IEEE 802.3cd, QSFP28 MSA, 100G Lambda MSA |
