Huawei CloudEngine CE8850-64CQ-EI 64×100G QSFP28 + 2×10G SFP+ Switch
Huawei CE8850-64CQ-EI Data Center Core Switch
The Huawei CloudEngine CE8850-64CQ-EI is a high-performance Layer 3 switch designed for data center core and aggregation layers. It offers 64 × 100GE QSFP28 ports, providing high-density 100G access. With a switching capacity of 12.8 Tbps and forwarding performance of 4,482 Mpps, this switch ensures efficient data handling. It supports advanced features such as intelligent stacking (iStack), comprehensive security mechanisms, and energy-efficient design, making it a versatile solution for various networking needs.
Overview
Highlights
-
Port Configuration: 64 × 100GE QSFP28 ports.
-
High Performance: Switching capacity of 12.8 Tbps and forwarding rate of 4,482 Mpps ensure efficient data processing.
-
Advanced Layer 3 Features: Supports static routing, RIP, OSPF, BGP, and IS-IS for robust network routing capabilities.
-
Comprehensive Security: Features include 802.1X authentication, MAC address filtering, DHCP snooping, ARP inspection, and port isolation.
-
Intelligent Stacking (iStack): Supports stacking of up to 16 switches, simplifying network management and enhancing scalability.
-
Energy-Efficient Design: Intelligent fan speed adjustment for reduced power consumption and noise.
-
Robust Management: Offers web-based management, SNMP v1/v2/v3, RMON, and CLI via console or Telnet.
Recommended Accessories
| Product Model | Category | Description |
|---|---|---|
| QSFP-100G-SR4 | QSFP28 Transceiver | 100GBASE-SR4 QSFP28, 850nm, multimode fiber, up to 100m |
| QSFP-100G-LR4 | QSFP28 Transceiver | 100GBASE-LR4 QSFP28, 1310nm, single-mode fiber, up to 10km |
| QSFP-100G-ER4 | QSFP28 Transceiver | 100GBASE-ER4 QSFP28, 1550nm, single-mode fiber, up to 40km |
| QSFP-100G-ZR4 | QSFP28 Transceiver | 100GBASE-ZR4 QSFP28, 1550nm, single-mode fiber, up to 80km |
| QSFP-100G-CU1M | QSFP28 Cable | 1-meter QSFP28 direct attach copper cable |
| QSFP-100G-CU3M | QSFP28 Cable | 3-meter QSFP28 direct attach copper cable |
| QSFP-100G-CU5M | QSFP28 Cable | 5-meter QSFP28 direct attach copper cable |
Comparison with Similar Items
| Feature | CE8850-64CQ-EI | CE8850-32CQ-EI | CE8861-4C-EI |
|---|---|---|---|
| Downlink Ports | 64 × 100GE QSFP28 | 32 × 100GE QSFP28 | Up to 128 × 10/25GE |
| Switching Capacity | 12.8 Tbps | 6.4 Tbps | 6.4 Tbps |
| Forwarding Rate | 4,482 Mpps | 3,200 Mpps | 2,030 Mpps |
| Stacking Support | Yes (up to 16) | Yes (up to 16) | Yes (up to 16) |
| Power Supply | Dual hot-swappable | Dual hot-swappable | Dual hot-swappable |
| Ideal Use Case | Core/Aggregation | Core/Aggregation | Modular Access |
Specifications
| Parameter | Specification |
|---|---|
| Model | CE8850-64CQ-EI |
| Downlink Ports | 64 × 100GE QSFP28 ports |
| Switching Capacity | 12.8 Tbps |
| Forwarding Rate | 4,482 Mpps |
| MAC Address Table | 264K entries |
| VLANs | Supports up to 4,096 VLANs (IEEE 802.1Q) |
| QoS | 8 queues per port, SP, WRR, and SP+WRR scheduling algorithms |
| IPv6 Features | IPv6 host, static routes, OSPFv3, BGP4+, IS-ISv6 |
| Security Features | 802.1X, MAC filtering, DHCP snooping, ARP inspection, port isolation |
| Management | Web-based, CLI, Telnet, SNMP v1/v2/v3, RMON, SSHv2 |
| Power Supply | Dual hot-swappable power modules (AC/DC) |
| Power Consumption | Typical: 455W; Maximum: 965W |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Dimensions (W×D×H) | 442 mm × 600 mm × 86.1 mm (17.4 in. × 23.6 in. × 3.4 in.) |
| Weight | ≤ 22.2 kg (48.9 lbs) |
| Warranty | Limited lifetime warranty |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Huawei HCIE Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Huawei products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
