NSComm S5760C-24SFP/8GT8XS-X 24x1G SFP Combo & 8x10G SFP+ L3 Switch
NS‑S5760C‑24SFP/8GT8XS‑X, 24×1 Gbps SFP+ 8×10 Gbps SFP+ Ports with 8×Combo RJ45, Core Switch
Overview
Includes 24× SFP downlinks (some combo ports), 8×10 GbE uplinks; delivers line-speed routing and redundancy with dual PSU and expansion module slot.
Highlights
-
Up to ~512 Mpps forwarding, 688 Gbps capacity
-
Flexible mix of SFP and combo copper ports for diverse deployment
-
Full Layer 3 routing features, VSU virtualization, redundant design
-
Same high-end reliability features as other models
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS‑PA150IB‑F | AC/DC Power Module | 150 W PSU required for operation |
| NS‑RMK‑1U | Rack Mount Kit | 19″ mounting brackets |
| NS‑M5000X Module | 100G Expansion Slot | For future uplink expansion |
Compare with Similar Models
| Model | Ports & Uplinks | Switching Capacity | Forwarding Rate | PoE/PoF Capability | Redundancy Features |
|---|---|---|---|---|---|
| Ruijie RG‑S5760C‑24GT8XS‑X | 24×1GbE RJ45, 8×10GbE SFP+ | 880 Gbps | 426 Mpps | None | Dual PSU, dual-flash boot, redundant fans |
| NS‑S5760C‑24GT8XS‑X | Same | Same | Same | None | Same |
| Ruijie RG‑S5760C‑48GT4XS‑X | 48×1GbE RJ45, 4×10GbE SFP+ | 880 Gbps | 402 Mpps | None | Dual PSU, dual-flash boot, redundant fans |
| NS‑S5760C‑48GT4XS‑X | Same | Same | Same | None | Same |
| Ruijie RG‑S5760C‑24SFP/8GT8XS‑X | 24×1GbE SFP, 8 Combo RJ45, 8×10GbE SFP+ | 688 Gbps | 512 Mpps | None | Dual PSU slots, fan redundancy, modular expansion |
| NS‑S5760C‑24SFP/8GT8XS‑X | Same | Same | Same | None | Same |
| Ruijie RG‑S5760C‑48SFP4XS‑X | 48×1GbE SFP, 4×10GbE SFP+ | 880 Gbps | 660 Mpps | None | Dual PSU slots, triple fan redundancy |
| NS‑S5760C‑48SFP4XS‑X | Same | Same | Same | None | Same |
| Ruijie RG‑S5760C‑48GT4XS‑HP‑X | 48×1GbE RJ45 PoE+, 4×10GbE SFP+ | 880 Gbps | 402 Mpps | ≤30 W/port, up to 1565 W total | Dual PSU slots, redundant fans |
| NS‑S5760C‑48GT4XS‑HP‑X | Same | Same | Same | Same | Same |
| Ruijie RG‑S5750‑24SFP4XS24DP‑UP | 24×1GbE SFP, 4×10GbE SFP+, 24×PoF hybrid ports | 1.28 Tbps | 396 Mpps | ≤100 W per PoF port, ≤2400 W total | Triple PSU slots, triple fan redundancy |
| NS‑S5750‑24SFP4XS24DP‑UP | Same | Same | Same | Same | Same |
Specification Summary
| Parameter | Details |
|---|---|
| Model | NS‑S5760C‑24SFP/8GT8XS‑X |
| Ports | 24×GE SFP (combo ports support 100/1000 Mb), 8×10 GE SFP+ uplinks |
| Switching Capacity | 688 Gbps |
| Forwarding Rate | ~512 Mpps |
| MAC / ARP Tables | ~64K / 24K |
| Routing Table | ~24K entries |
| Redundancy Features | Dual PSU slots, hot-swap fans, expansion slot |
| Physical | 440×340×44 mm; ~4.4 kg |
| Operating Temp. | 0–45 °C |
| Surge Protection | 6 kV/10 kV per interface |
