NSComm S5760C-24GT8XS-X 24x1G & 8x10G SFP+ L3 Core/Aggregation Switch
NS‑S5760C‑24GT8XS‑X, 24×1 Gbps RJ45 + 8×10 Gbps SFP+ Layer 3 Aggregation Switch
Overview
This model delivers 24 × 1 GbE access ports and 8 × 10 GbE SFP+ uplinks, designed for high-performance campus aggregation or enterprise core. Featuring 880 Gbps switching capacity, up to ~426 Mpps forwarding rate, and dual redundant 1 + 1 power modules.
Highlights
-
880 Gbps switching capacity, ~426 Mpps forwarding
-
Up to 64K MAC, 24K ARP, 24K routing table entries
-
Rich L2+/L3 protocols: VLAN/VXLAN, RIP, OSPF, BGP, IS-IS, ACLs, QoS, multicast (IGMP/PIM)
-
VSU virtualization, millisecond failover and unified management
-
Hardware-level redundancy: dual power modules, dual flash boot, hot-swappable fans
-
Robust management: SNMP, CLI, Web UI, RMON, Syslog, USB log backup, cloud/APP options
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS‑PA150IB‑F | AC/DC Power Module | 150 W module compatible with this model |
| NS‑RMK‑1U | Rack Mount Kit | 19″ 1U mounting kit |
| NS‑M5000X Module | 40/100 G QSFP Expansion | For higher‑speed uplink expansion |
Compare with Similar Models
| Model | Ports & Uplinks | Switching Capacity | Forwarding Rate | PoE/PoF Capability | Redundancy Features |
|---|---|---|---|---|---|
| Ruijie RG‑S5760C‑24GT8XS‑X | 24×1GbE RJ45, 8×10GbE SFP+ | 880 Gbps | 426 Mpps | None | Dual PSU, dual-flash boot, redundant fans |
| NS‑S5760C‑24GT8XS‑X | Same | Same | Same | None | Same |
| Ruijie RG‑S5760C‑48GT4XS‑X | 48×1GbE RJ45, 4×10GbE SFP+ | 880 Gbps | 402 Mpps | None | Dual PSU, dual-flash boot, redundant fans |
| NS‑S5760C‑48GT4XS‑X | Same | Same | Same | None | Same |
| Ruijie RG‑S5760C‑24SFP/8GT8XS‑X | 24×1GbE SFP, 8 Combo RJ45, 8×10GbE SFP+ | 688 Gbps | 512 Mpps | None | Dual PSU slots, fan redundancy, modular expansion |
| NS‑S5760C‑24SFP/8GT8XS‑X | Same | Same | Same | None | Same |
| Ruijie RG‑S5760C‑48SFP4XS‑X | 48×1GbE SFP, 4×10GbE SFP+ | 880 Gbps | 660 Mpps | None | Dual PSU slots, triple fan redundancy |
| NS‑S5760C‑48SFP4XS‑X | Same | Same | Same | None | Same |
| Ruijie RG‑S5760C‑48GT4XS‑HP‑X | 48×1GbE RJ45 PoE+, 4×10GbE SFP+ | 880 Gbps | 402 Mpps | ≤30 W/port, up to 1565 W total | Dual PSU slots, redundant fans |
| NS‑S5760C‑48GT4XS‑HP‑X | Same | Same | Same | Same | Same |
| Ruijie RG‑S5750‑24SFP4XS24DP‑UP | 24×1GbE SFP, 4×10GbE SFP+, 24×PoF hybrid ports | 1.28 Tbps | 396 Mpps | ≤100 W per PoF port, ≤2400 W total | Triple PSU slots, triple fan redundancy |
| NS‑S5750‑24SFP4XS24DP‑UP | Same | Same | Same | Same | Same |
Specification Summary
| Parameter | Details |
|---|---|
| Model | NS‑S5760C‑24GT8XS‑X |
| Ports | 24×1 GbE RJ45 + 8×10 GbE SFP+ uplinks |
| Switching Capacity | 880 Gbps |
| Forwarding Rate | ~426 Mpps |
| MAC / ARP Table | 64K / 24K entries |
| Routing Table | IPv4/IPv6 ~24K routes |
| Redundancy Features | Dual power slots, dual flash boot, hot-swappable fans & power modules |
| Physical | 440×340×44 mm; ~4.4 kg; left‑to‑right airflow |
| Operating Temp. | 0 °C to 45 °C, non‑condensing humidity |
| Protection | Surge protection: 6 kV on power port, 10 kV telecom port |
