NSComm S5360-48GT4XS-E 48x1G & 4x10G SFP+ L3 Managed Switch
NS‑S5360‑48GT4XS‑E, 48 × 1 Gbps RJ45 + 4 × 10 Gbps SFP+ Layer 3 Managed Switch
As a trusted OEM partner alongside Cisco, H3C, Huawei, and Ruijie, NSComm offers exactly the same hardware, firmware (RGOS 12.X), and industrial‑grade reliability of Ruijie’s RG‑S5360‑24GT4XS‑E under your brand label.
Our NS‑S5360‑E series delivers enterprise‑grade Layer 3 routing, virtualization (VSU), robust security, and flexibility of uplinks and PoE configurations across 24‑port and 48‑port models.
Overview
48 × 1 Gbps downlinks and 4 × 1/2.5/10 Gbps SFP+ uplinks, delivering 211 Gbps switching capacity and 158 Mpps forwarding rate, perfect for high-density access scenarios.
Highlights
-
211 Gbps / 158 Mpps maximum throughput
-
Full support for Layer 2+/Layer 3 protocols: ACLs, routing (IPv4/IPv6), ERPS, CPP, NFPP
-
Industrial-grade resilience: nano-coating, –40 °C to +65 °C range, 10 kV surge protection
-
Dual hot-swap power design
-
VSU-enabled virtualization for simplified management
-
Multi-interface management: SNMP, CLI, Web, Telnet, TR‑069 zero‑touch
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS‑PA70IB | AC Power Module | 70 W module for base power supply |
| NS‑PA600I‑P‑F | AC Power Module | 600 W PSU option for scalability |
| NS‑PA1000I‑P‑F | AC Power Module | 1000 W PSU for redundancy |
| NS‑XG‑SFP‑SR | SFP+ Transceiver | 10 G SR transceiver (850 nm multimode) |
| NS‑RMK‑1U | Rack Mount Kit | 19″ 1 U rackmount kit |
Compare with Similar Models
| Model | Ports & Uplinks | Capacity / Forwarding | PoE+ Budget | Power Redundancy |
|---|---|---|---|---|
| Ruijie RG‑S5360‑24GT4XS‑E | 24 × GE + 4 × 10 GE SFP+ | 154 Gbps / 115 Mpps | None | Dual hot-swap PSUs |
| NS‑S5360‑24GT4XS‑E | Same | Same | None | Same |
| Ruijie RG‑S5360‑48GT4XS‑E | 48 × GE + 4 × 10 GE SFP+ | 211 Gbps / 158 Mpps | None | Dual PSUs |
| NS‑S5360‑48GT4XS‑E | Same | Same | None | Same |
| Ruijie RG‑S5360‑24GT4XS‑P‑E | 24 × GE PoE+ + 4 × 10 GE SFP+ | 154 Gbps / 115 Mpps | Up to 740 W | PoE PSU Redundancy |
| NS‑S5360‑24GT4XS‑P‑E | Same | Same | Same | Same |
| Ruijie RG‑S5360‑48GT4XS‑P‑E | 48 × GE PoE+ + 4 × 10 GE SFP+ | 211 Gbps / 158 Mpps | Up to 1440 W | PoE PSU Redundancy |
| NS‑S5360‑48GT4XS‑P‑E | Same | Same | Same | Same |
Specification Summary
| Parameter | Specification |
|---|---|
| Model | NS‑S5360‑48GT4XS‑E |
| Ports | 48×1 GbE RJ45 downlinks, 4×1/2.5/10 GbE SFP+ uplinks |
| Switching Capacity | 211 Gbps |
| Forwarding Rate | 158 Mpps |
| MAC Table Size | 16,000 entries |
| ARP Table Size | 4,000 entries |
| IPv4 Unicast Routes | ~6,000 |
| Power Supply Slots | 2 × pluggable modules, 1+1 redundancy |
| Power Consumption | ≤30 W (no load) |
| Operating Temp. | –40 °C to +65 °C |
| Dimensions | 442×420×43.6 mm, ~4.4 kg |
| Protection | Nano‑coating, IP40, 10 kV surge resistance |
| Management & OS | SNMP/Web/CLI/Telnet/USB/TR‑069 (INC/cloud) |
