H3C S5130S-28S-PWR-EI 24x1G + 4x10G + PoE+ Access Switch
H3C S5130S-28S-PWR-EI Fiber PoE Access Switch
Overview
The H3C S5130S-28S-PWR-EI is a fiber-based Gigabit PoE+ access switch featuring 24 × 1G SFP downlinks, 4 × 1G/PoE RJ45 combo ports, and 4 × 10GE uplinks. With PoE+ capability, it is ideal for fiber-to-the-floor deployments requiring power delivery for APs, surveillance cameras, or IoT devices.
Note: Comes with built-in AC PoE power.
Highlights
1. 24×SFP Fiber Access + 4×Combo PoE Ports
Fiber-rich access design with combo copper ports supporting PoE+ for AP/IP cameras.
2. 4 × 10GE SFP+ Uplinks
Ensures high uplink bandwidth for campus distribution.
3. Enterprise L2/L3 Services
Supports full routing functions (static, RIP, OSPF), VLAN, ACL, DHCP security, and IPv6.
4. Stable PoE Architecture
Integrated AC PoE power supply provides efficient and reliable power delivery.
Recommended Accessories
| Accessory | Model | Category | Description |
|---|---|---|---|
| Power | Built-in AC PoE PSU | Power | Integrated PoE power unit. |
| Cooling | Internal fixed fan | Cooling | Non-removable fan system. |
| 1G SFP Optics | SFP-1G-SX / SFP-1G-LX | Optics | Recommended for 1G fiber access. |
| 10G Uplink Optics | SFP-10G-SR / LR | Optics | For uplink connections. |
| PoE Cabling | - | Cabling | Cat6/Cat6A recommended for PoE devices. |
Comparison with Similar Models
| Feature | S5130S-28S-PWR-EI | S5130S-28S-EI | S5130S-28S-HPWR-EI-AC |
|---|---|---|---|
| Downlinks | 24×1G SFP + 4×Combo PoE | 24×1G SFP | 24×1G SFP + PoE UPoE |
| Uplinks | 4×10G | 4×10G | 4×10G |
| PoE | PoE+ | No | High-power UPoE |
| Best Use | Fiber + PoE floors | Fiber-only | High-power fiber PoE |
Specifications
| Parameter | Specification |
|---|---|
| Model | S5130S-28S-PWR-EI |
| Downlink Ports | 24 × 1G SFP |
| Combo Ports | 4 × 1G RJ45 PoE+ |
| Uplink Ports | 4 × 10GE SFP+ |
| PoE Standard | IEEE 802.3af/at |
| Switching | Full wire-speed |
| Routing | Static, RIP, OSPF, VRRP |
| Security | ACL, DHCP Snooping, IP Source Guard |
| VLAN Support | 4K |
| QoS | WRR/WFQ, shaping, policing |
| IPv6 | Supported |
| Virtualization | IRF |
| O&M | sFlow, Telemetry, SNMP/iMC |
| Power | Built-in AC PoE |
| Cooling | Internal fixed fan |
| Operating Temperature | 0°C to +50°C |
| Use Case | Fiber-based PoE access, AP/camera aggregation |
