H3C S5130S-28S-EI 24x1G + 4x1/2.5/10G SFP+ Gigabit/10G Access Switch
H3C S5130S-28S-EI Gigabit SFP Access Switch
Overview
The H3C S5130S-28S-EI is a fiber-based Gigabit access switch featuring 24 × 1G SFP ports and 4 × 10GE SFP+ uplinks. Ideal for fiber-to-the-desk, aggregation in fiber-rich campuses, and long-distance optical access scenarios. It supports L2/L3 enterprise features including OSPF, VRRP, DHCP security, ACL, and IRF virtualization.
Note: Integrated AC PSU and internal fan.
Highlights
1. 24-Port Fiber Access
suited for optical campus deployments or EMI-sensitive environments that require fiber distribution.
2. 4 × 10GE Uplinks
Enables high-speed aggregation to distribution/core switches.
3. Complete Enterprise L2/L3 Feature Set
IPv4/IPv6 routing, VLAN, ACL, DHCP security, QoS, IRF, and OSPF.
4. Stable & Easy to Operate
Built-in AC PSU, integrated fans, Telemetry, SNMP, and centralized iMC support.
Recommended Accessories
| Accessory | Model | Category | Description |
|---|---|---|---|
| Power | Integrated AC PSU | Power | No modular PSU required. |
| Cooling | Internal fixed fan | Cooling | Non-modular. |
| SFP Modules | SFP-1G-SX / SFP-1G-LX | Optics | Recommended 1G fiber downlink modules. |
| 10G Uplinks | SFP-10G-SR / LR | Optics | Standard uplink transceivers. |
Comparison with Similar Models
| Feature | S5130S-28S-EI | S5130S-28P-EI | S5130S-52S-PWR-EI-AC |
|---|---|---|---|
| Downlinks | 24×1G SFP | 24×1G RJ45 | 48×1G SFP PoE |
| Uplinks | 4×10G | 4×10G | 4×10G |
| Medium | Fiber | Copper | Fiber/PoE hybrid |
| Best Use | Fiber-rich access | Standard access | Fiber PoE access |
Specifications
| Parameter | Specification |
|---|---|
| Model | S5130S-28S-EI |
| Downlink Ports | 24 × 1G SFP |
| Uplink Ports | 4 × 10GE SFP+ |
| Switching | Full wire-speed |
| L3 Features | OSPF, RIP, static, VRRP |
| VLAN | 4K |
| Security | ACL, DHCP Snooping, ARP/ND guard |
| QoS | Traffic shaping, scheduling, WRR |
| IPv6 | Supported |
| Virtualization | IRF |
| Power | Integrated AC PSU |
| Cooling | Internal fixed fan |
| Operating Temperature | 0°C to +50°C |
| Best Deployment | Fiber campus access, EMI-sensitive environments, long-distance access |
