NSComm 400G OSFP to OSFP Direct Attach PVC Copper Cable, up to 3m
400G OSFP to OSFP Direct Attach Copper Cable (DAC), PVC, Passive, up to 3 m (10 ft)
Overview
The NSComm 400G OSFP to OSFP Direct Attach Copper Cable (DAC) is a cost-effective, ultra-low latency interconnect solution for 400 Gigabit Ethernet short-reach applications in hyperscale data centers, cloud environments, and HPC clusters. With integrated OSFP connectors on both ends, this DAC eliminates the need for separate optical transceivers and patch cords, delivering plug-and-play performance.
Built with twinax copper conductors and a durable PVC jacket, the passive DAC supports lengths up to 3 m (10 ft) while consuming virtually no power. For extended deployments, active copper DACs reach up to 5 m (16 ft) at ≤ 4 W per end, ensuring efficiency and reliability. It offers excellent EMI immunity, robust signal integrity, and consistent low latency.
Need to check compatibility with your specific hardware? [Contact Us Now] for support.
Key Specifications
| Specification | Details |
|---|---|
| Vendor Name | NSComm |
| Product Type | 400G OSFP to OSFP Direct Attach Copper Cable (DAC) |
| Data Rate | 400 Gbps (8×50 Gbps PAM4 lanes) |
| Cable Type | Twinax Copper, PVC Jacket, Passive/Active |
| Max Cable Distance | Passive: up to 3 m (10 ft); Active: up to 5 m (16 ft) |
| Conductor AWG Options | 30 AWG (≤ 2 m), 26 AWG (≤ 3 m), 24 AWG (active ≤ 5 m) |
| Connector Type | OSFP to OSFP |
| Power Consumption | Passive ≈ 0 W, Active ≤ 4 W |
| Temperature Range | 0 °C to 70 °C |
| Standards Compliance | OSFP MSA, IEEE 802.3bs, RoHS |
| Applications | 400G switch-to-switch interconnects, server uplinks, leaf-spine links |
Why Choose NSComm 400G OSFP DAC?
-
High-speed connectivity: Supports full 400G Ethernet bandwidth.
-
Plug-and-play: No optics or patch cords required.
-
Ultra-low latency: Direct electrical path for minimal delay.
-
Energy efficient: Passive consumes no power; active ≤ 4 W.
-
Vendor interoperability: Validated across all leading switch and server platforms.
Length Options
Standard stocked lengths:
1 m (3 ft), 2 m (7 ft), 3 m (10 ft)
Extended (active) lengths:
5 m (16 ft)
